Harley-Davidson Tri Glide Ultra - 2018 Specifications and Reviews
The 2018 Harley-Davidson Tri Glide Ultra is a three-wheeled cruiser designed for riders seeking maximum comfort and stability on long journeys. Its signature features include a spacious trunk, windshield, cruise control, and low-slung seating that accommodate larger riders and passengers with exceptional carrying capacity. Known for its distinctive trike configuration and smooth Twin Cam engine, it delivers classic Harley character with added security and convenience technology.
General information | |
| Category | Touring |
| Year | 2018 |
| Model | Harley-Davidson Tri Glide Ultra |
| | |
Engine and Transmission Specifications | |
| Exhaust system | Chrome, 2-1-2 dual exhaust with tapered mufflers |
| Greenhouse gases | 153.1 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel consumption | 6.60 litres/100 km (15.2 km/l or 35.64 mpg) |
| Driveline | Chain, 34/46 ratio primary drive |
| Clutch | Multi-plate with diaphragm spring in oil bath |
| Transmission type,final drive | Belt |
| Gearbox | 6-speed |
| Cooling system | Air |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Fuel system | Injection. Electronic Sequential Port Fuel Injection (ESPFI) |
| Bore x Stroke | 100.0 x 111.1 mm (3.9 x 4.4 inches) |
| Compression | 10.0:1 |
| Torque | 152.00 Nm (15.5 kgf-m or 112.1 ft.lbs) @ 3250 RPM |
| Power | 87.00 HP (63.5 kW) @ 5450 RPM |
| Engine details | Twin-Cooled™ Milwaukee-Eight® 107 |
| Engine type | V2, four-stroke |
| | |
Brakes, suspension, Frame and wheels | |
| Wheels | Black, 7-spoke Cast Aluminum. Two rear wheels. |
| Rear brakes | Single disc |
| Front brakes | Double disc. 6 piston. |
| Rear tyre | 205/65-R15 |
| Front tyre | MT90-B16 |
| Front Suspension | Telescopic fork |
| Trail | 100 mm (3.9 inches) |
| Rake (fork angle) | 26.0° |
Physical measures and capacities | |
| Oil capacity | 4.70 litres (0.31 quarts) |
| Fuel capacity | 22.71 litres (6.00 gallons) |
| Wheelbase | 1,670 mm (65.7 inches) |
| Ground clearance | 125 mm (4.9 inches) |
| Overall length | 2,675 mm (105.3 inches) |
| Seat height | 735 mm (28.9 inches) If adjustable, lowest setting. |
| Power/weight ratio | 0.1593 HP/kg |
| Weight incl. oil, gas, etc | 564.0 kg (1,243.4 pounds) |
| Dry weight | 546.0 kg (1,203.7 pounds) |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Comments | Trike. Windshield. Cruise control. Alarm. Foot actuated dual parking brake. |
| Carrying capacity | Trunk and top box |
| Light | High Beam, running lights, front fender running lights, directional light bar, low oil pressure, engine diagnostics, cruise control, speakers, accessory, security system (optional), 6 speed, low fuel warning, reverse enabled |
| Instruments | Large speedometer and tachometer with wide numbers; large fuel and volt gauges with wide numbers; display features odometer, trip A, trip B, range to empty, and gear indicator; and larger telltale indicators, including new reverse indicator light |
| Starter | Electric |
| Color options | Vivid Black, Black Tempest, Silver Fortune/Sumatra Brown, Twisted Cherry/Silver Fortune, Wicked Red/Twisted Cherry, Legend Blue/Vivid Black |
Performance Profile & Rider Fit
93 hp
Peak Power
6.5s
0-60 mph
Best For
Track3%
City28%
Cornering15%
Daily Riding35%
Touring96%
Passenger92%
Rider Profile
| Best For | Great for riders who want touring luxury without balancing a two-wheeler; its trike layout suits returning, aging, or mobility-limited riders, though its size still demands respect. |
| Purpose | Built for long-haul two-up touring in maximum comfort, hauling gear in its trunk and top box across highways and open roads. |
| Rider Fit | Massive 561kg three-wheeler with a low 688mm seat, wide stance, full fairing, floorboards, audio, and electric reverse for easy parking. |
| Character | A rolling luxury lounge - stable, planted, torque-rich and unhurried, delivering effortless mile-munching with no need to balance or put a foot down. |
| Not Ideal For | Not for anyone chasing agility, canyon carving, track days, tight city filtering, or off-road use; it steers like a car, not a motorcycle. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
Rider Reviews
Total comments: 1
MotorcycleDB Review
The 2018 Harley-Davidson Tri Glide Ultra is a top-of-the-line three-wheeled motorcycle that offers a smooth and comfortable ride for long-distance touring. Powered by a powerful Milwaukee-Eight 107 engine, this trike delivers strong performance and impressive acceleration. The spacious and luxurious cockpit features a Boom! Box GTS infotainment system, navigation, and ample storage space, making it an ideal choice for long-haul trips. With its iconic Harley-Davidson styling and impeccable build quality, the Tri Glide Ultra is a standout option for riders looking for a reliable and stylish three-wheeled motorcycle. If you're in the market for a premium three-wheeled motorcycle, the 2018 Harley-Davidson Tri Glide Ultra is a must-see. Its powerful engine, comfortable ride, and high-end features make it a standout option for touring enthusiasts. With its cutting-edge technology and classic design, this trike combines performance with comfort for an unforgettable riding experience. Whether you're cruising down the open road or navigating city streets, the Tri Glide Ultra is a versatile and reliable choice for riders looking for a top-of-the-line touring motorcycle.Add a Comment
