Harley-Davidson Tri Glide Ultra - 2023 Specifications and Reviews
The 2023 Harley-Davidson Tri Glide Ultra is a premium three-wheeled touring cruiser designed for riders seeking ultimate comfort and stability on long-distance journeys. Powered by the Milwaukee-Eight 114 V-twin engine delivering 100 horsepower and 164 Nm of torque, it offers smooth, commanding performance paired with advanced touring amenities. Best known for its exceptional handling, spacious seating, and legendary Harley character, it's ideal for experienced cruiser enthusiasts prioritizing comfort and confidence.
General information | |
| Category | Touring |
| Year | 2023 |
| Model | Harley-Davidson Tri Glide Ultra |
Engine and Transmission Specifications | |
| Exhaust system | 2-1-2 dual exhaust with tapered mufflers |
| Greenhouse gases | 129.9 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel consumption | 5.60 litres/100 km (17.9 km/l or 42.00 mpg) |
| Driveline | Chain, 34/46 ratio primary drive |
| Clutch | Multi-plate with diaphragm spring in oil bath |
| Transmission type | Belt (final drive) |
| Gearbox | 6-speed |
| Cooling system | Air |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Fuel system | Injection. Electronic Sequential Port Fuel Injection |
| Bore x Stroke | 102.0 x 114.3 mm (4.0 x 4.5 inches) |
| Compression | 10.5:1 |
| Torque | 164.1 Nm (16.7 kgf-m or 121.0 ft.lbs) @ 3250 RPM |
| Power | 100.0 HP (73.0 kW) @ 5000 RPM |
| Engine details | Twin-Cooled™ Milwaukee-Eight® 114 |
| Engine type | V2, four-stroke |
| Capacity: | 1868.0 ccm (113.99 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Wheels | Black, 7-spoke cast aluminum. Two rear wheels. Dunlop® Harley-Davidson Series, bias blackwall tires. |
| Rear brakes | Single disc. ABS. Integrated park brake. |
| Front brakes | Double disc. ABS. 4 piston. |
| Rear tire | 205/65-R15 |
| Front tire | MT90-B16 |
| Rear Suspension | Hand-adjustable emulsion rear suspension |
| Front Suspension | Telescopic fork, 49mm dual bending valve |
| Trail | 100 mm (3.9 inches) |
| Rake (fork angle) | 26.0° |
Physical measures and capacities | |
| Oil capacity | 4.70 litres (4.97 US quarts) |
| Fuel capacity | 22.71 litres (6.00 US gallons) |
| Wheelbase | 1670 mm (65.7 inches) |
| Ground clearance | 125 mm (4.9 inches) |
| Overall length | 2670 mm (105.1 inches) |
| Seat height | 688 mm (27.1 inches) If adjustable, lowest setting. |
| Power/weight ratio | 0.1831 HP/kg |
| Weight incl. oil, gas, etc | 563.8 kg (1,243.0 pounds) |
| Dry weight | 546.1 kg (1,204.0 pounds) |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Comments | Trike. Windshield. Traction control. Cruise control. Slip control. Electronic linked braking. Alarm. Infotainment. USB. Bluetooth. Foot actuated dual parking brake. |
| Carrying capacity | Trunk and top box. 6.8 cu ft luggage volume. |
| Light | All LED lighting |
| Instruments | 6.5 inch color TFT. Speedometer, tachometer, fuel, and voltage gauges; display features odometer, trip A, trip B, range to empty, gear indicator |
| Starter | Electric |
| Color options | Vivid Black, Atlas Silver Metallic, Gray Haze/Silver Fortune, Prospect Gold/Vivid Black |
Performance Profile & Rider Fit
93 hp
Peak Power
6.5s
0-60 mph
Best For
Track3%
City28%
Cornering15%
Daily Riding35%
Touring96%
Passenger92%
Rider Profile
| Best For | Great for riders who want touring luxury without balancing a two-wheeler; its trike layout suits returning, aging, or mobility-limited riders, though its size still demands respect. |
| Purpose | Built for long-haul two-up touring in maximum comfort, hauling gear in its trunk and top box across highways and open roads. |
| Rider Fit | Massive 561kg three-wheeler with a low 688mm seat, wide stance, full fairing, floorboards, audio, and electric reverse for easy parking. |
| Character | A rolling luxury lounge - stable, planted, torque-rich and unhurried, delivering effortless mile-munching with no need to balance or put a foot down. |
| Not Ideal For | Not for anyone chasing agility, canyon carving, track days, tight city filtering, or off-road use; it steers like a car, not a motorcycle. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
Rider Reviews
Total comments: 1
MotorcycleDB Review
The 2023 Harley-Davidson Tri Glide Ultra is a powerful and sleek three-wheeler that provides an ultimate riding experience. With its cutting-edge technology, comfortable seating, and exceptional handling, this trike is perfect for long road trips and weekend getaways. The impressive Milwaukee-Eight 117 engine delivers outstanding performance, making it a standout choice for motorcycle enthusiasts looking for a reliable and robust ride. In addition to its powerful engine, the 2023 Harley-Davidson Tri Glide Ultra offers innovative features such as the Reflex Defensive Rider Systems (RDRS) and the Boom! Box GTS infotainment system, ensuring a safe and entertaining journey. The spacious trunk and storage compartments make it easy to pack for extended trips, while the adjustable rear suspension provides a smooth and comfortable ride. Overall, the 2023 Harley-Davidson Tri Glide Ultra is a top-of-the-line touring trike that combines style, performance, and practicality, making it an ideal choice for riders seeking a premium and unforgettable riding experience.Add a Comment
