Benelli TNT 135 - 2024 Specifications and Reviews
No pictures availableGeneral information | |
| Price as new | Do you know this bike?Click here to rate it. We miss 1 vote to show the rating. |
| Category | Minibike, sport |
| Model year | 2024 |
| Motorcycle name | Benelli TNT 135 |
| | |
Engine and Transmission Specifications | |
| Exhaust system | Underbody muffler with dual exhaust with catalytic converter and oxygen sensors |
| Clutch | Wet multi-plate |
| Transmission type | Chain (final drive) |
| Gearbox | 5-speed |
| Cooling system | Oil & air |
| Lubrication system | Pressure splash lubrication |
| Ignition | Delphi MT 05 |
| Fuel control | Single Overhead Cams (SOHC) |
| Fuel system | Injection |
| Valves per cylinder | 4 |
| Bore x stroke | 54.0 x 58.5 mm (2.1 x 2.3 inches) |
| Compression | 9.8:1 |
| Torque | 10.8 Nm (1.1 kgf-m or 8.0 ft.lbs) @ 7000 RPM |
| Power output | 12.5 HP (9.1 kW)) @ 9000 RPM |
| Engine type | Single cylinder, four-stroke |
| Capacity: | 134.7 ccm (8.22 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Wheels | Aluminum alloy |
| Rear brakes | Single disc |
| Diameter | 220 mm (8.7 inches) |
| Front brakes | Single disc. 2-piston caliper |
| Rear tire | 130/70-12 |
| Front tire | 120/70-12 |
| Rear wheel travel | 50 mm (2.0 inches) |
| Rear suspension | Telescopic coil spring oil damped |
| Front wheel travel | 120 mm (4.7 inches) |
| Front suspension | Telescopic forks, 41mm |
| Frame type | Arch bar truck |
Physical measures and capacities | |
| Fuel capacity | 7.20 litres (1.90 US gallons) |
| Wheelbase | 1215 mm (47.8 inches) |
| Ground clearance | 160 mm (6.3 inches) |
| Overall width | 755 mm (29.7 inches) |
| Overall length | 1770 mm (69.7 inches) |
| Overall height | 1025 mm (40.4 inches) |
| Seat height | 780 mm (30.7 inches) If adjustable, lowest setting. |
| Power/weight ratio | 0.1075 HP/kg |
| Dry weight | 116.0 kg (255.7 pounds) |
Other specs | |
| Comments | Chinese made bike. |
| Starter | Electric |
| Color options | Red/white, black/red, green, white, grey |
