Honda CRF50F - 2024 Specifications and Reviews
General information | |
| Category | Minibike, sport |
| Year | 2024 |
| Model name | Honda Dax 125 |
| | |
Engine and Transmission Specifications | |
| Emission details | Euro 5 |
| Greenhouse gases | 34.8 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel consumption | 1.50 litres/100 km (66.7 km/l or 156.81 mpg) |
| Clutch | Wet Multiplate and Automatic Centrifugal Clutch |
| Transmission type | Chain (final drive) |
| Gearbox | 4-speed |
| Cooling system | Air |
| Ignition | Fully transistorized |
| Fuel control | Single Overhead Cams (SOHC) |
| Fuel system | Injection. PGM-FI with automatic enrichment |
| Valves per cylinder | 2 |
| Bore x stroke | 50.0 x 63.1 mm (2.0 x 2.5 inches) |
| Compression | 10.0:1 |
| Torque | 10.8 Nm (1.1 kgf-m or 8.0 ft.lbs) @ 5000 RPM |
| Power | 9.3 HP (6.8 kW)) @ 7000 RPM |
| Engine type | Single cylinder, four-stroke |
| Capacity: | 124.9 ccm (7.62 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Wheels | 5-spoke cast aluminium |
| Rear brakes | Single disc. Hydraulic. ABS. |
| Diameter | 220 mm (8.7 inches) |
| Front brakes | Single disc. Hydraulic. ABS. |
| Rear tire | 130/70-12 |
| Front tire | 120/70-12 |
| Rear wheel travel | 120 mm (4.7 inches) |
| Rear suspension | Twin shocks |
| Front wheel travel | 100 mm (3.9 inches) |
| Front suspension | 31mm inverted fork |
| Trail | 84 mm (3.3 inches) |
| Rake (fork angle) | 24.9° |
| Frame type | Press backbone |
Physical measures and capacities | |
| Oil capacity | 1.00 litres (1.06 US quarts) |
| Reserve fuel capacity | 1.89 litres (0.50 US gallons) |
| Fuel capacity | 5.68 litres (1.50 US gallons) |
| Wheelbase | 1200 mm (47.2 inches) |
| Ground clearance | 175 mm (6.9 inches) |
| Overall width | 760 mm (29.9 inches) |
| Overall length | 1760 mm (69.3 inches) |
| Overall height | 1020 mm (40.2 inches) |
| Seat height | 775 mm (30.5 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 104.0 kg (229.3 pounds) |
Other specs | |
| Update specs | |
| Factory warranty | One Year Unlimited-mileage |
| Light | LED lights |
| Electrical | 12 3.5Ah battery |
| Instruments | LCD meter |
| Starter | Electric |
| Color options | Pearl Cadet Grey, Pearl Nebula Red |
