Benelli TNT 135 - 2023 Specifications and Reviews

2024

2023

2020

2018

2017

❮❯

Add/Upload pictures for this motorcycle

General information
Price as new	Do you know this bike?Click here to rate it. We miss 1 vote to show the rating.
Category	Minibike, sport
Year	2023
Model	Benelli TNT 135
Engine and Transmission Specifications
Exhaust system	Underbody muffler with dual exhaust with catalytic converter and oxygen sensors
Clutch	Wet multi-plate
Transmission type	Chain (final drive)
Gearbox	5-speed
Cooling system	Oil & air
Lubrication system	Pressure splash lubrication
Ignition	Delphi MT 05
Fuel control	Single Overhead Cams (SOHC)
Fuel system	Injection
Valves per Cylinder	4
Bore x Stroke	54.0 x 58.5 mm (2.1 x 2.3 inches)
Compression	9.8:1
Torque	10.8 Nm (1.1 kgf-m or 8.0 ft.lbs) @ 7000 Revolutions">RPM
Power	12.5 Horsepower">HP (9.1 Kilowatt">kW)) @ 9000 Revolutions">RPM
Engine type	Single cylinder, four-stroke
Capacity:	134.7 ccm (8.22 cubic inches)
Brakes, suspension, Frame and wheels
Wheels	Aluminum alloy
Rear brakes	Single disc
Diameter	220 mm (8.7 inches)
Front brakes	Single disc. 2-piston caliper
Rear tire	130/70-12
Front tire	120/70-12
Rear wheel travel	50 mm (2.0 inches)
Rear Suspension	Telescopic coil spring oil damped
Front wheel travel	120 mm (4.7 inches)
Front Suspension	Telescopic forks, 41mm
Frame type	Arch bar truck

Physical measures and capacities
Fuel capacity	7.20 litres (1.90 US gallons)
Wheelbase	1215 mm (47.8 inches)
Ground clearance	160 mm (6.3 inches)
Overall width	755 mm (29.7 inches)
Overall length	1770 mm (69.7 inches)
Overall height	1025 mm (40.4 inches)
Seat height	780 mm (30.7 inches) If adjustable, lowest setting.
Power/weight ratio	0.1075 HP/kg
Dry weight	116.0 kg (255.7 pounds)
Other specs
Comments	Chinese made bike.
Starter	Electric
Color options	Red/white, black/red, green, white, grey

Rider Reviews

Total comments: 1

MotorcycleDB Review

The 2023 Benelli TNT 135 is an impressive small-displacement motorcycle that offers excellent performance and agility. With its 135cc single-cylinder engine, the TNT 135 delivers a thrilling riding experience, especially for urban commuters and beginner riders. The bike's lightweight design, nimble handling, and responsive brakes make it easy to maneuver through city traffic and tight corners. Additionally, the TNT 135 features a stylish and modern design that is sure to turn heads on the road. Overall, the 2023 Benelli TNT 135 is a fantastic option for riders looking for a fun and practical motorcycle that is easy to handle. Whether you're navigating through city streets or hitting the open road, the TNT 135 offers a great balance of performance, comfort, and style. If you're in the market for a small-displacement bike that offers a big punch, the TNT 135 is definitely worth considering.
