What category is the 2010 Lehman Trikes PitBoss?

The 2010 Lehman Trikes PitBoss has a Category of Custom / cruiser.

What is the engine size of the 2010 Lehman Trikes PitBoss?

The 2010 Lehman Trikes PitBoss has a Capacity: of 1638.81 ccm (100.00 cubic inches).

What type of engine does the 2010 Lehman Trikes PitBoss have?

The 2010 Lehman Trikes PitBoss has a Engine type of V2, four-stroke.

Is the 2010 Lehman Trikes PitBoss air cooled or liquid cooled?

The 2010 Lehman Trikes PitBoss has a Cooling system of Oil & air.

How many gears does the 2010 Lehman Trikes PitBoss have?

The 2010 Lehman Trikes PitBoss has a Gearbox of 6-speed.

How much does the 2010 Lehman Trikes PitBoss weigh?

The 2010 Lehman Trikes PitBoss has a Dry weight of 440.0 kg (970.0 pounds).

What is the seat height of the 2010 Lehman Trikes PitBoss?

The 2010 Lehman Trikes PitBoss has a Seat height of 673 mm (26.5 inches) If adjustable, lowest setting..

Lehman Trikes PitBoss - 2010 Specifications and Reviews

Name: 2010 Lehman Trikes PitBoss
Brand: Lehman Trikes

The 2010 Lehman Trikes PitBoss is a custom cruiser trike powered by a 1638cc V-twin engine, designed for riders seeking stable, low-slung three-wheel cruising with distinctive styling. Its fuel-injected engine and six-speed transmission deliver reliable performance, while the aggressive 32.8-degree rake and belt drive characterize its laid-back cruiser character.

⇄ Compare against another bike 📅 All Years

2010

❮❯

Add/Upload pictures for this motorcycle

General information
Category	Custom / cruiser
Year	2010
Model	Lehman Trikes PitBoss
Engine and Transmission Specifications
Clutch	Wet, multi-plate
Transmission type,final drive	Belt
Gearbox	6-speed
Cooling system	Oil & air
Fuel control	SOHC
Fuel system	Injection. 45mm throttle bodies
Valves per cylinder	4
Bore x stroke	101.0 x 102.0 mm (4.0 x 4.0 inches)
Compression	8.7:1
Engine type	V2, four-stroke
Capacity:	1638.81 ccm (100.00 cubic inches)

Brakes, suspension, Frame and wheels
Rear brakes diameter	300 mm (11.8 inches)
Rear brakes	Single disc
Front brakes diameter	300 mm (11.8 inches)
Front brakes	Single disc
Rear tyre dimensions	180/55-B18
Front tyre dimensions	130/70-B18
Rear suspension travel	100 mm (3.9 inches)
Rear suspension	Single, mono-tube gas,cast aluminum with rising rate linkage , 3.9in/100mm travel, preload adjustable spring
Front suspension travel	130 mm (5.1 inches)
Front suspension	Inverted cartridge telescopic fork, 43mm diameter, 5.1in/130mm travel
Rake (fork angle)	32.8°
Physical measures and capacities
Fuel capacity	17.03 litres (4.50 gallons)
Wheelbase	1,664 mm (65.5 inches)
Ground clearance	147 mm (5.8 inches)
Overall width	1,346 mm (53.0 inches)
Overall length	2,743 mm (108.0 inches)
Seat height	673 mm (26.5 inches) If adjustable, lowest setting.
Dry weight	440.0 kg (970.0 pounds)

Other specs
Maintenance	Find parts, fluids, filters, maintenance tools and service items on eBay
Starter	Electric

Performance Profile & Rider Fit

8.5s

0-60 mph (est.)

Best For

Track5%

City30%

Cornering20%

Daily Riding45%

Touring65%

Passenger70%

Rider Profile

Best For	Best suited to experienced riders who have specifically trained for or are comfortable with three-wheeled trike handling dynamics, which differ significantly from two-wheeled motorcycles.
Purpose	Built for relaxed, stable cruising and boulevard presence rather than performance riding, leveraging its big V-twin torque and trike stability.
Rider Fit	The trike's substantial weight and wide footprint remove the balance demands of a normal bike but require confidence with its size and low-speed maneuvering at parking lot speeds.
Character	A laid-back, torque-rich cruiser with custom trike styling that prioritizes stability, visual presence, and relaxed long-distance comfort over agility.
Not Ideal For	Not for riders seeking sharp cornering ability, off-road capability, or a lightweight, flickable riding experience.

Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.

Rider Fit Visualizer

2010 Lehman Trikes PitBoss Rider Ergonomics Assessment

Your height

Inseam (optional)

Units

Calculated in your browser only - your height/inseam are never sent to our servers.

Feet:

At 673mm, a rider of 175cm with a 79cm (estimated) inseam will reach the ground with both feet flat on the 2010 Lehman Trikes PitBoss, with a cramped knee angle of around 75 degrees and an upright riding position.

Data quality: measured. Assumes about 30mm of suspension sag once seated (a typical street-bike rule of thumb - stiffer or softer suspension will vary). This is an approximation from category-typical geometry and generic body proportions, not a measurement of this specific bike or you - sit on it before you buy.
