Kawasaki KLX230SM - 2024 Specifications and Reviews
The 2024 Kawasaki KLX230SM is an entry-level supermoto designed for riders seeking an affordable, nimble urban machine with genuine off-road capability. Its lightweight 233cc single-cylinder engine and compact chassis make it ideal for beginners and experienced riders alike who value maneuverability and fun over raw power. Known for its versatility, the KLX230SM excels both on pavement and light trails.
General information | |
| Price as new | Do you know this bike?Click here to rate it. We miss 2 votes to show the rating. |
| Category | Super motard |
| Model year | 2024 |
| Model | Kawasaki KLX230SM |
| | |
Engine and Transmission Specifications | |
| Driveline | Sealed chain |
| Clutch | Wet multi-disc, manual |
| Transmission type | Chain (final drive) |
| Gearbox | 6-speed |
| Cooling system | Air |
| Lubrication system | Forced lubrication, wet sump |
| Ignition | TCBI Electronic Advance |
| Fuel control | Single Overhead Cams (SOHC) |
| Fuel system | Injection. DFI® with 32mm Keihin throttle body |
| Valves per cylinder | 4 |
| Bore x stroke | 67.0 x 66.0 mm (2.6 x 2.6 inches) |
| Compression | 9.4:1 |
| Engine type | Single cylinder, four-stroke |
| Capacity: | 233.0 ccm (14.22 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Wheels | Wire spoked. Road tyres. |
| Rear brakes | Single disc. Single-piston. Petal disc. Optional ABS. |
| Diameter | 300 mm (11.8 inches) |
| Front brakes | Single disc. Dual-piston. Petal disc. Optional ABS. |
| Rear tire | 120/70-17 |
| Front tire | 110/70-17 |
| Rear wheel travel | 218 mm (8.6 inches) |
| Rear suspension | Uni-Trak® linkage system and single shock with adjustable spring preload |
| Front wheel travel | 203 mm (8.0 inches) |
| Front suspension | 37mm telescopic fork |
| Trail | 117 mm (4.6 inches) |
| Rake (fork angle) | 27.5° |
| Frame type | High-tensile steel, box-section perimeter |
| | |
Physical measures and capacities | |
| Fuel capacity | 7.57 litres (2.00 US gallons) |
| Wheelbase | 1374 mm (54.1 inches) |
| Ground clearance | 231 mm (9.1 inches) |
| Overall width | 836 mm (32.9 inches) |
| Overall length | 2050 mm (80.7 inches) |
| Overall height | 1120 mm (44.1 inches) |
| Seat height | 846 mm (33.3 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 134.0 kg (295.5 pounds) |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Update specs | |
| Factory warranty | 12 months |
| Light | LED headlight |
| Instruments | Digital |
| Starter | Electric |
| Color options | Lime Green, Oriental Blue |
Performance Profile & Rider Fit
12.5s
0-60 mph (est.)
Best For
Track40%
City75%
Cornering70%
Daily Riding55%
Touring20%
Passenger20%
Rider Profile
| Best For | Best suited to beginner and intermediate riders who want a light, unintimidating bike to build confidence on tight, twisty roads. |
| Purpose | This is a lightweight supermoto designed for playful street riding, urban commuting, and darting through tight corners rather than outright speed or distance. |
| Rider Fit | Its low 129 kg dry weight and slim single-cylinder chassis make it easy to handle for shorter or less experienced riders, though the 841 mm seat height is fairly tall for a supermoto. |
| Character | A fun, flickable, low-displacement machine that rewards momentum-carrying riding style over raw power. |
| Not Ideal For | It is not a good fit for riders wanting highway touring capability, a passenger-friendly setup, or strong straight-line acceleration. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
