GAS GAS Gas EC 500F - 2025 Specifications and Reviews
The 2025 GAS GAS EC 500F is a hard-hitting enduro machine built for experienced riders who demand raw power and precision control in challenging terrain. Its 510cc liquid-cooled four-stroke engine with advanced Keihin fuel injection delivers responsive performance, while the 6-speed gearbox and sophisticated DDS clutch provide excellent adaptability across varying conditions.
2025
General information | |
| Color Options | Red/black |
| Category | Enduro / offroad |
| Year | 2025 |
| Model | GAS GAS EC 500F |
| | |
Engine and Transmission Specifications | |
| Starting | Electric |
| Clutch | DDS wet multi-disc clutch, Braktec hydraulics |
| Final Drive | Chain (final drive) |
| Gearbox | 6-speed |
| Cooling System | Liquid |
| Ignition | Keihin EMS |
| Fuel Control | Overhead Cams (OHC) |
| Induction | Injection. Keihin EFI, throttle body 42 mm |
| Valves Per Cylinder | 5 |
| Bore x Stroke | 95.0 x 72.0 mm (3.7 x 2.8 inches) |
| Compression Ratio | 12.8:1 |
| Engine Type | Single cylinder, four-stroke |
| Capacity: | 510.9 ccm (31.18 cubic inches) |
Physical measures and capacities | |
| Fuel Capacity | 9.00 litres (2.38 US gallons) |
| Wheelbase | 1489 mm (58.6 inches) |
| Ground Clearance | 343 mm (13.5 inches) |
| Overall Width | 830 mm (32.7 inches) |
| Overall Length | 2200 mm (86.6 inches) |
| Overall Height | 1260 mm (49.6 inches) |
| Seat Height | 956 mm (37.6 inches) If adjustable, lowest setting. |
| Dry Weight | 111.7 kg (246.3 pounds) |
| | |
GAS GAS Gas EC 500F dimensions and frame | |
| Wheels | 21 x 1.60´; 18 x 2.15´ |
| Rear Brakes | Single disc |
| Brake Disc Diameter | 220 mm (8.7 inches) |
| Front Brakes | Single disc |
| Rear Tyre | 140/80-18 |
| Front Tyre | 90/90-21 |
| Rear Wheel Travel | 300 mm (11.8 inches) |
| Rear Suspension | WP XACT Monoshock with linkage |
| Front Wheel Travel | 300 mm (11.8 inches) |
| Front Suspension | WP XPLOR-USD, 48 mm |
| Frame | Central double-cradle-type 25CrMo4 steel. Subframe: Aluminium. |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Update specs | Report missing specs or required updates. |
| Comments | Spanish made bike. |
| Electrical | 2 Ah battery. |
| Rake (fork angle) | 26.1° |
| Exhaust system | Aluminium |
| Driveline | 520 X-Ring. Primary drive: 29:72. Final drive: 14:50. |
Performance Profile & Rider Fit
Best For
Track20%
City15%
Cornering55%
Daily Riding20%
Touring30%
Passenger5%
Rider Profile
| Best For | This is a serious enduro machine best suited to experienced off-road riders who are comfortable with a tall seat height, minimal weight, and big-bore torque delivery. |
| Purpose | Built purely for demanding off-road enduro riding, including technical trails, hills, and competition-level terrain rather than street commuting. |
| Rider Fit | The tall 956mm seat height and lightweight but physically demanding riding style favor taller, fit riders used to standing and shifting body weight actively on rough terrain. |
| Character | It has the character of a raw, high-torque enduro weapon: light, nimble, eager off idle, and designed to reward aggressive, skillful throttle and body input over technical ground. |
| Not Ideal For | This is not the right bike for beginners, commuters, passengers, or anyone wanting a comfortable, low-effort road or touring machine. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
