Kawasaki KFX90 - 2024 Specifications and Reviews
The 2024 Kawasaki KLR 650 S is a versatile super motard designed for riders seeking adventure both on and off pavement. Its liquid-cooled 652cc single-cylinder engine delivers reliable torque across the RPM range, while the nimble chassis excels at mixed-terrain riding. Best known for balanced performance and practical everyday usability, it suits intermediate to experienced riders prioritizing adventure capability.
2024
General information | |
| Price as new | Do you know this bike?Click here to rate it. We miss 2 votes to show the rating. |
| Category | Super motard |
| Year | 2024 |
| Model name | Kawasaki KLR 650 S |
| | |
Engine and Transmission Specifications | |
| Driveline | Sealed chain |
| Clutch | Wet multi-disc manual clutch |
| Transmission type | Chain (final drive) |
| Gearbox | 5-speed |
| Cooling system | Liquid |
| Ignition | CDI |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Fuel system | Injection. DFI w/40mm Throttle Body |
| Bore x stroke | 100.0 x 83.0 mm (3.9 x 3.3 inches) |
| Compression | 9.8:1 |
| Torque | 53.0 Nm (5.4 kgf-m or 39.1 ft.lbs) @ 4500 RPM |
| Engine type | Single cylinder, four-stroke |
| Capacity: | 652.0 ccm (39.79 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Wheels | Wire spoked |
| Rear brakes | Single disc. Single piston. Optional ABS.. |
| Diameter | 300 mm (11.8 inches) |
| Front brakes | Single disc. Two-piston calipers. Optional ABS. |
| Rear tire | 130/80-17 |
| Front tire | 90/90-21 |
| Rear wheel travel | 185 mm (7.3 inches) |
| Rear suspension | Uni-Trak® single shock with adjustable rebound damping and adjustable spring preload |
| Front wheel travel | 170 mm (6.7 inches) |
| Front suspension | 41mm telescopic fork |
| Trail | 117 mm (4.6 inches) |
| Rake (fork angle) | 29.5° |
| Frame type | Tubular, Semi-Double Cradle |
Physical measures and capacities | |
| Oil capacity | 2.50 litres (2.64 US quarts) |
| Fuel capacity | 23.09 litres (6.10 US gallons) |
| Wheelbase | 1514 mm (59.6 inches) |
| Ground clearance | 185 mm (7.3 inches) |
| Overall width | 970 mm (38.2 inches) |
| Overall length | 2256 mm (88.8 inches) |
| Overall height | 1466 mm (57.7 inches) |
| Seat height | 815 mm (32.1 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 206.9 kg (456.2 pounds) |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Comments | Small windscreen. ABS adds 4.4 lbs. |
| Factory warranty | 12 months |
| Carrying capacity | Aluminum rear carrier |
| Light | LED headlight |
| Starter | Electric |
| Color options | Pearl Storm Gray, Candy Lime Green |
Maintenance and service data | |
| Fork tube size | 38 mm (1.5 inches) |
| Tire pressure rear | 29 PSI (2 Bar or 200 kPa) |
| Tire pressure front | 22 PSI (1.5 Bar or 150 kPa) |
| Sprockets | 15/43 (front/rear) |
| Chain links | 106 |
| Idle speed | 1300 +/- 100 RPM |
| Spark plugs | NGK DPR8EA-9, NGK DPR8EIX-9 |
| Coolant | 1.00 litres (0.26 US gallons) |
| Brake fluid | DOT 4 |
Performance Profile & Rider Fit
9.5s
0-60 mph (est.)
Best For
Track15%
City45%
Cornering40%
Daily Riding55%
Touring65%
Passenger40%
Rider Profile
| Best For | Note: the specifications provided are actually for the Kawasaki KLR650 S, a dual-sport, not the KFX90 ATV, so this profile reflects that adventure-touring single instead; it suits riders with at least some prior motorcycling experience due to its tall sea |
| Purpose | This machine is built as a rugged dual-sport for mixed on- and off-road adventure riding rather than outright speed or track use. |
| Rider Fit | The tall seat height and long-travel suspension mean shorter or lighter riders may find it a stretch, and its 207kg weight demands moderate strength at low speeds or off-road recovery. |
| Character | It has the personality of a dependable, unhurried explorer, torquey and simple, more interested in covering rough terrain reliably than chasing lap times. |
| Not Ideal For | This is not the right choice for riders seeking sharp cornering performance, high top-end power, or a sporty road-focused riding experience. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
