CH Racing CH 510 Basic Big Wheels - 2010 Specifications and Reviews
The 2010 CH Racing CH 510 Basic Big Wheels is a lightweight minibike designed for young riders and beginners seeking an affordable entry into off-road riding. Powered by a modest 49.7cc two-stroke engine, it delivers playful performance suitable for trails and recreational use. Its bigger wheels compared to typical minibikes provide improved stability and ground clearance for novice riders.
2010
Engine and Transmission Specifications | |
| Transmission type,final drive | Chain |
| Cooling system | Air |
| Fuel system | Carburettor. DELL´ORTO PHBG 14 MS |
| Power | 3.50 |
| Engine type | Single cylinder, two-stroke |
| Capacity: | 49.70 ccm (3.03 cubic inches) |
| Category | Minibike, cross |
| Year | 2010 |
| Model | CH Racing CH 510 Basic Big Wheels |
| | |
Brakes, suspension, Frame and wheels | |
| Rear brakes | Expanding brake (drum brake) |
| Front brakes diameter | 175 mm (6.9 inches) |
| Front brakes | Single disc |
| Rear tyre dimensions | 3.00-12 |
| Front tyre dimensions | 2.50-14 |
| Rear suspension | Single shock absorber |
| Front suspension | Telescopic fork |
| | |
Physical measures and capacities | |
| Fuel capacity | 2.80 litres (0.74 gallons) |
| Wheelbase | 1,100 mm (43.3 inches) |
| Ground clearance | 280 mm (11.0 inches) |
| Overall length | 1,500 mm (59.1 inches) |
| Seat height | 734 mm (28.9 inches) If adjustable, lowest setting. |
| Power/weight ratio | 0.0921 HP/kg |
| Weight incl. oil, gas, etc | 42.0 kg (92.6 pounds) |
| Dry weight | 38.0 kg (83.8 pounds) |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Color options | Blue/yellow |
| Starter | Kick |
Performance Profile & Rider Fit
3.5 hp
Peak Power
Best For
Track15%
City10%
Cornering40%
Daily Riding10%
Touring5%
Passenger0%
Rider Profile
| Best For | This is a machine for young or beginner riders, typically children or very small novice riders taking their first steps on two wheels. |
| Purpose | Built as a small-capacity minibike for casual backyard riding, learning basic bike control, and light recreational cross-style play rather than any serious competition or transport use. |
| Rider Fit | Its tiny 38 kg dry weight and low 734 mm seat height make it extremely easy to handle, pick up, and manage for lightweight or younger riders. |
| Character | A playful, low-powered pit-bike style minibike with simple two-stroke charm, nimble handling, and no pretensions of speed or long-distance capability. |
| Not Ideal For | This is not suitable for adult commuting, highway travel, touring, carrying a passenger, or anyone seeking real performance or power. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
