What category is the 2009 CH Racing CH 510 Basic Big Wheels?

The 2009 CH Racing CH 510 Basic Big Wheels has a Category of Minibike, cross.

What is the engine size of the 2009 CH Racing CH 510 Basic Big Wheels?

The 2009 CH Racing CH 510 Basic Big Wheels has a Capacity: of 49.70 ccm (3.03 cubic inches).

What type of engine does the 2009 CH Racing CH 510 Basic Big Wheels have?

The 2009 CH Racing CH 510 Basic Big Wheels has a Engine type of Single cylinder.

What is the engine power of the 2009 CH Racing CH 510 Basic Big Wheels?

The 2009 CH Racing CH 510 Basic Big Wheels has a Power of 3.50.

Is the 2009 CH Racing CH 510 Basic Big Wheels air cooled or liquid cooled?

The 2009 CH Racing CH 510 Basic Big Wheels has a Cooling system of Air.

How much does the 2009 CH Racing CH 510 Basic Big Wheels weigh?

The 2009 CH Racing CH 510 Basic Big Wheels has a Dry weight of 38.0 kg (83.8 pounds).

What is the seat height of the 2009 CH Racing CH 510 Basic Big Wheels?

The 2009 CH Racing CH 510 Basic Big Wheels has a Seat height of 734 mm (28.9 inches) If adjustable, lowest setting..

CH Racing CH 510 Basic Big Wheels - 2009 Specifications and Reviews

Name: 2009 CH Racing CH 510 Basic Big Wheels
Brand: CH Racing

The 2009 CH Racing CH 510 Basic Big Wheels is a lightweight minibike designed for young riders and beginners seeking an accessible entry point into motorcycling. Powered by a modest 49.7cc single-cylinder engine producing 3.5 horsepower, it prioritizes simplicity and ease of handling with its compact dimensions and 38kg dry weight. Known for its straightforward air-cooled design and reliable kick-start operation, this machine excels as an economical trainer bike for developing fundamental riding skills.

⇄ Compare against another bike 📅 All Years

2010

2009

❮❯

CH Racing CH 510 Basic Big Wheels 2009 20336 Thumb

Add/Upload pictures for this motorcycle

Engine and Transmission Specifications
Transmission typefinal drive	Chain
Cooling system	Air
Starter	Kick
Fuel system	Carburettor. DELL´ORTO PHBG 14 MS
Power	3.50
Stroke	2
Engine type	Single cylinder
Capacity:	49.70 ccm (3.03 cubic inches)
Physical measures and capacities
Wheelbase	1,100 mm (43.3 inches)
Ground clearance	280 mm (11.0 inches)
Overall width	630 mm (24.8 inches)
Overall length	1,500 mm (59.1 inches)
Seat height	734 mm (28.9 inches) If adjustable, lowest setting.
Dry weight	38.0 kg (83.8 pounds)

CH Racing CH 510 Basic Big Wheels dimensions and frame
Rear brakes	Expanding brake (drum brake)
Front brakes diameter	175 mm (6.9 inches)
Front brakes	Single disc
Rear tyre dimensions	3.00-12
Front tyre dimensions	2.50-14
Rear suspension	Single shock absorber
Front suspension	Telescopic fork
Speed and acceleration
Power/weight ratio	0.0921 HP/kg


Category	Minibike, cross
Year	2009
Model	CH Racing CH 510 Basic Big Wheels
Other specs
Maintenance	Find parts, fluids, filters, maintenance tools and service items on eBay
Color options	Blue/yellow
Fuel capacity	2.80 litres (0.74 gallons)

Performance Profile & Rider Fit

3.5 hp

Peak Power

Best For

Track15%

City10%

Cornering40%

Daily Riding10%

Touring5%

Passenger0%

Rider Profile

Best For	This is a machine for young or beginner riders, typically children or very small novice riders taking their first steps on two wheels.
Purpose	Built as a small-capacity minibike for casual backyard riding, learning basic bike control, and light recreational cross-style play rather than any serious competition or transport use.
Rider Fit	Its tiny 38 kg dry weight and low 734 mm seat height make it extremely easy to handle, pick up, and manage for lightweight or younger riders.
Character	A playful, low-powered pit-bike style minibike with simple two-stroke charm, nimble handling, and no pretensions of speed or long-distance capability.
Not Ideal For	This is not suitable for adult commuting, highway travel, touring, carrying a passenger, or anyone seeking real performance or power.

Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
