What category is the 2016 Zero Engineering Type 5-B?

The 2016 Zero Engineering Type 5-B has a Category of Custom / cruiser.

What is the engine size of the 2016 Zero Engineering Type 5-B?

The 2016 Zero Engineering Type 5-B has a Capacity: of 1570.00 ccm (95.80 cubic inches).

What type of engine does the 2016 Zero Engineering Type 5-B have?

The 2016 Zero Engineering Type 5-B has a Engine type of V2, four-stroke.

Is the 2016 Zero Engineering Type 5-B air cooled or liquid cooled?

The 2016 Zero Engineering Type 5-B has a Cooling system of Air.

How many gears does the 2016 Zero Engineering Type 5-B have?

The 2016 Zero Engineering Type 5-B has a Gearbox of 5-speed.

How much does the 2016 Zero Engineering Type 5-B weigh?

The 2016 Zero Engineering Type 5-B has a Weight incl. oil, gas, etc of 250.0 kg (551.2 pounds).

What is the seat height of the 2016 Zero Engineering Type 5-B?

The 2016 Zero Engineering Type 5-B has a Seat height of 660 mm (26.0 inches) If adjustable, lowest setting..

Zero Engineering Type 5-B - 2016 Specifications and Reviews

Name: 2016 Zero Engineering Type 5-B
Brand: Zero Engineering

The 2016 Zero Engineering Type 5-B is a retro-styled cruiser that appeals to riders seeking classic Japanese motorcycle aesthetics with modern reliability. Known for its distinctive springer fork front suspension and gooseneck steel frame, this air-cooled machine delivers accessible performance through a carbureted engine and five-speed transmission, making it ideal for enthusiasts who value vintage character over cutting-edge technology.

⇄ Compare against another bike 📅 All Years

2016

❮❯

Zero Engineering Type 5-B 2016 50291 Thumb

Add/Upload pictures for this motorcycle

General information
Category	Custom / cruiser
Year	2016
Model	Zero Engineering Type 5-B
Engine and Transmission Specifications
Driveline	Haraley Davidson transmission
Clutch	Wet multiplate coil spring
Transmission type,final drive	Chain
Gearbox	5-speed
Cooling system	Air
Ignition	Mircotech
Fuel control	Overhead Valves (OHV)
Fuel system	Carburettor. Injection in Japan
Valves per cylinder	4
Bore x Stroke	88.8 x 108.0 mm (3.5 x 4.3 inches)
Engine type	V2, four-stroke
Capacity:	1570.00 ccm (95.80 cubic inches)
Brakes, suspension, Frame and wheels
Seat	Single person leather seat, various colors
Rear brakes	Single disc. Hydraulic
Front brakes	Single disc. Hydraulic
Rear tyre	5.00-16
Front tyre	5.00-16
Rear Suspension	Rigid
Front Suspension	Springer fork
Rake (fork angle)	33.2°
Frame type	Gooseneck steel pipes frame

Physical measures and capacities
Oil capacity	2.80 litres (0.18 quarts)
Fuel capacity	8.40 litres (2.22 gallons)
Wheelbase	1,600 mm (63.0 inches)
Ground clearance	100 mm (3.9 inches)
Overall width	720 mm (28.3 inches)
Overall length	2,300 mm (90.6 inches)
Overall height	930 mm (36.6 inches)
Seat height	660 mm (26.0 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc	250.0 kg (551.2 pounds)

Other specs
Maintenance	Find parts, fluids, filters, maintenance tools and service items on eBay
Comments	Zero Engineering is a Japanese brand.
Instruments	Compact analogue
Starter	Electric
Color options	Black/chrome

Performance Profile & Rider Fit

Best For

Track5%

City40%

Cornering25%

Daily Riding35%

Touring25%

Passenger5%

Rider Profile

Best For	Best suited to experienced riders comfortable with a heavy, rigid-rear custom cruiser that demands deliberate, low-speed handling skills.
Purpose	Built as a boutique Japanese custom cruiser for style-focused, low-speed boulevard riding rather than outright performance.
Rider Fit	The low 660mm seat height suits shorter riders, but the rigid rear suspension and springer front fork mean every road imperfection is felt directly, favoring riders with good core and back tolerance.
Character	This bike speaks to riders who value hand-built aesthetics, classic hardtail styling, and V-twin character over speed or modern refinement.
Not Ideal For	Not suited for riders seeking long-distance touring comfort, passenger accommodation, spirited cornering, or any off-road capability.

Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.

Rider Fit Visualizer

2016 Zero Engineering Type 5-B Rider Ergonomics Assessment

Your height

Inseam (optional)

Units

Calculated in your browser only - your height/inseam are never sent to our servers.

Feet:

At 660mm, a rider of 175cm with a 79cm (estimated) inseam will reach the ground with both feet flat on the 2016 Zero Engineering Type 5-B, with a cramped knee angle of around 70 degrees and an upright riding position.

Data quality: measured. Assumes about 30mm of suspension sag once seated (a typical street-bike rule of thumb - stiffer or softer suspension will vary). This is an approximation from category-typical geometry and generic body proportions, not a measurement of this specific bike or you - sit on it before you buy.

Find bikes that fit your height →
