Yamaha XSR700 - 2024 Specifications and Reviews
The 2024 Yamaha XSR700 is a lightweight retro-modern middleweight that appeals to riders seeking nimble handling and classic styling with contemporary technology. Known for its approachable 689cc parallel-twin engine and manageable seat height, it excels as both an everyday commuter and weekend canyon carver. Its compact dimensions and responsive character make it ideal for riders prioritizing agility and versatility over raw power.
General information | |
| Price as new | Do you know this bike?Click here to rate it. We miss 2 votes to show the rating. |
| Type | Classic |
| Year model | 2024 |
| Model name | Yamaha XSR700 |
Engine and Transmission Specifications | |
| Emission details | Euro 4 |
| Greenhouse gases | 94.2 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel consumption | 4.06 litres/100 km (24.6 km/l or 57.94 mpg) |
| Driveline | Constant Mesh |
| Clutch | Wet, multiplate |
| Transmission type | Chain (final drive) |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Lubrication system | Wet sump |
| Ignition | Transistor Controlled Ignition |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Fuel system | Injection |
| Valves per cylinder | 4 |
| Bore x stroke | 80.0 x 68.6 mm (3.1 x 2.7 inches) |
| Compression | 11.5:1 |
| Torque | 68.0 Nm (6.9 kgf-m or 50.2 ft.lbs) @ 6500 RPM |
| Effect | 73.8 HP (53.8 kW)) @ 9000 RPM |
| Engine details | Vibration-reducing counterbalancer |
| Type of engine | Twin, four-stroke |
| Capacity: | 689.0 ccm (42.04 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Seat | Two-level seat |
| Wheels | 10-spoke cast aluminum. Michelin® Road 5 tyres |
| Rear brakes | Single disc. Hydraulic. ABS. |
| Diameter | 282 mm (11.1 inches) |
| Front brakes | Double disc. Hydraulic. ABS. |
| Rear tire | 180/55-ZR17 |
| Front tire | 120/70-ZR17 |
| Rear wheel travel | 130 mm (5.1 inches) |
| Rear suspension | Single shock, adjustable preload |
| Front wheel travel | 130 mm (5.1 inches) |
| Front suspension | 41mm telescopic fork |
| Trail | 90 mm (3.5 inches) |
| Rake (fork angle) | 25.0° |
| Frame type | Diamond |
| | |
Physical measures and capacities | |
| Oil capacity | 2.70 litres (2.85 US quarts) |
| Fuel capacity | 14.00 litres (3.70 US gallons) |
| Wheelbase | 1405 mm (55.3 inches) |
| Ground clearance | 140 mm (5.5 inches) |
| Overall width | 820 mm (32.3 inches) |
| Overall length | 2075 mm (81.7 inches) |
| Overall height | 1130 mm (44.5 inches) |
| Seat height | 835 mm (32.9 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 186.0 kg (410.0 pounds) |
| | |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Update specs | |
| Factory warranty | 1 Year Limited Factory Warranty |
| Light | LED Headlight |
| Instruments | LCD panel |
| Starter | Electric |
| Color options | Raven |
Performance Profile & Rider Fit
4s
0-60 mph (est.)
Best For
Track55%
City82%
Cornering80%
Daily Riding78%
Touring42%
Passenger45%
Rider Profile
| Best For | Well suited to newer and intermediate riders thanks to its manageable weight and approachable torque delivery, while still rewarding more experienced riders in twisty environments. |
| Purpose | A versatile retro-styled roadster built primarily for spirited city riding, weekend backroad fun, and light café-racer style cruising rather than outright speed or long-distance touring. |
| Rider Fit | The low-ish seat height combined with a compact, lightweight chassis makes it accessible to riders of varying inseams and physical strength. |
| Character | Offers a charismatic, torquey CP2 twin-cylinder feel with agile, flickable handling that encourages playful riding over raw straight-line performance. |
| Not Ideal For | Not the ideal choice for riders seeking high-speed touring comfort, long highway range, or any genuine off-road capability. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
