Yamaha XMAX 300 Tech MAX - 2024 Specifications and Reviews
The 2024 Yamaha XMAX 300 Tech Max is a premium urban scooter designed for commuters and riders seeking practical daily transportation with advanced technology. Known for its spacious underseat storage, full LED lighting, and traction control, it combines modern conveniences like keyless ignition and a 4.3-inch LCD display with genuine riding capability for city and suburban use.
General information | |
| Category | Scooter |
| Year | 2024 |
| Model name | Yamaha XMAX 300 Tech Max |
Engine and Transmission Specifications | |
| Emission details | Euro 5 |
| Greenhouse gases | 69.6 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel consumption | 3.00 litres/100 km (33.3 km/l or 78.41 mpg) |
| Driveline | V-Belt Automatic |
| Transmission type | Belt (final drive) |
| Gearbox | Automatic |
| Cooling system | Liquid |
| Lubrication system | Wet sump |
| Ignition | TCI |
| Fuel control | Single Overhead Cams (SOHC) |
| Fuel system | Injection |
| Valves per cylinder | 4 |
| Bore x stroke | 70.0 x 75.9 mm (2.8 x 3.0 inches) |
| Compression | 10.9:1 |
| Torque | 29.0 Nm (3.0 kgf-m or 21.4 ft.lbs) @ 5750 RPM |
| Power | 27.6 HP (20.2 kW)) @ 7250 RPM |
| Engine details | Euro 5 Blue Core engine |
| Engine type | Single cylinder, four-stroke |
| Capacity: | 292.0 ccm (17.82 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Rear brakes | Single disc. Hydraulic. ABS. |
| Diameter | 267 mm (10.5 inches) |
| Front brakes | Single disc. Hydraulic. ABS. |
| Rear tire | 140/70-14 |
| Front tire | 120/70-15 |
| Rear wheel travel | 79 mm (3.1 inches) |
| Rear suspension | Unit Swing |
| Front wheel travel | 110 mm (4.3 inches) |
| Front suspension | Telescopic forks |
| Frame type | Underbone |
Physical measures and capacities | |
| Oil capacity | 1.30 litres (1.37 US quarts) |
| Fuel capacity | 13.20 litres (3.49 US gallons) |
| Wheelbase | 1540 mm (60.6 inches) |
| Ground clearance | 135 mm (5.3 inches) |
| Overall width | 795 mm (31.3 inches) |
| Overall length | 2180 mm (85.8 inches) |
| Overall height | 1410 mm (55.5 inches) |
| Seat height | 795 mm (31.3 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 183.0 kg (403.4 pounds) |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Update specs | |
| Comments | Traction Control. Keyless. Windscreen. |
| Carrying capacity | Underseat storage for 2 full-face helmets |
| Light | Full LED lighting |
| Instruments | 4.3-inch LCD instruments |
| Starter | Electric |
| Color options | Dark Petrol, Tech Black |
Performance Profile & Rider Fit
27.6 hp
Peak Power
8.5s
0-60 mph
Best For
Track5%
City92%
Cornering55%
Daily Riding90%
Touring55%
Passenger72%
Rider Profile
| Best For | Approachable for newer riders thanks to twist-and-go automatic transmission, yet refined enough to satisfy experienced commuters wanting fuss-free daily transport. |
| Purpose | Premium maxi-scooter built for urban commuting and light touring, blending easy city agility with weather protection and generous storage. |
| Rider Fit | Moderate 795mm seat, step-through underbone frame, adjustable windscreen and comfortable upright seating. At 183kg it's manageable but feels planted at speed. |
| Character | Tech-laden, effortless and practical - keyless start, traction control, TFT-adjacent LCD, and two-helmet underseat storage make it a sophisticated everyday companion. |
| Not Ideal For | Not for track days, off-road use, or riders craving big-bore highway punch or the engagement of a manual gearbox. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
