Yamaha XMAX 300 - 2024 Specifications and Reviews
The 2024 Yamaha XMAX 300 is a premium maxi-scooter designed for commuters and touring riders seeking comfort and practicality. Known for its spacious underseat storage, advanced traction control, and full LED lighting, it offers an accessible riding experience with modern technology and fuel efficiency. The adjustable windscreen and ergonomic seating make it ideal for both city commuting and longer weekend rides.
General information | |
| Type | Scooter |
| Year model | 2024 |
| Model | Yamaha XMAX 300 |
| | |
Engine and Transmission Specifications | |
| Emission details | Euro 5 |
| Greenhouse gases | 69.6 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel consumption | 3.00 litres/100 km (33.3 km/l or 78.41 mpg) |
| Driveline | V-Belt Automatic |
| Transmission type | Belt (final drive) |
| Gearbox | Automatic |
| Cooling system | Liquid |
| Lubrication system | Wet sump |
| Ignition | TCI |
| Fuel control | Single Overhead Cams (SOHC) |
| Fuel system | Injection |
| Valves per cylinder | 4 |
| Bore x stroke | 70.0 x 75.9 mm (2.8 x 3.0 inches) |
| Compression | 10.9:1 |
| Torque | 29.0 Nm (3.0 kgf-m or 21.4 ft.lbs) @ 5750 RPM |
| Effect | 27.6 HP (20.2 kW)) @ 7250 RPM |
| Engine details | Euro 5 Blue Core engine |
| Type of engine | Single cylinder, four-stroke |
| Capacity: | 292.0 ccm (17.82 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Rear brakes | Single disc. Hydraulic. ABS. |
| Diameter | 267 mm (10.5 inches) |
| Front brakes | Single disc. Hydraulic. ABS. |
| Rear tire | 140/70-14 |
| Front tire | 120/70-15 |
| Rear wheel travel | 79 mm (3.1 inches) |
| Rear suspension | Unit Swing |
| Front wheel travel | 110 mm (4.3 inches) |
| Front suspension | Telescopic forks |
| Frame type | Underbone |
Physical measures and capacities | |
| Oil capacity | 1.30 litres (1.37 US quarts) |
| Fuel capacity | 13.20 litres (3.49 US gallons) |
| Wheelbase | 1540 mm (60.6 inches) |
| Ground clearance | 135 mm (5.3 inches) |
| Overall width | 795 mm (31.3 inches) |
| Overall length | 2180 mm (85.8 inches) |
| Overall height | 1410 mm (55.5 inches) |
| Seat height | 795 mm (31.3 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 183.0 kg (403.4 pounds) |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Update specs | |
| Comments | Traction Control. Keyless. Windscreen. |
| Carrying capacity | Underseat storage for 2 full-face helmets |
| Light | Full LED lighting |
| Instruments | 4.3-inch LCD instruments |
| Starter | Electric |
| Color options | Icon Blue, Sonic Grey |
Performance Profile & Rider Fit
27.6 hp
Peak Power
9.5s
0-60 mph
Best For
Track10%
City92%
Cornering55%
Daily Riding90%
Touring68%
Passenger70%
Rider Profile
| Best For | Suitable for new to intermediate riders thanks to its automatic transmission and manageable weight. |
| Purpose | Designed primarily as a practical urban commuter with enough highway capability for occasional longer trips. |
| Rider Fit | A low seat height and light, automatic operation make it accessible to riders of most sizes and shorter inseams. |
| Character | A refined, comfortable maxi-scooter that blends everyday practicality with a touch of sporty styling. |
| Not Ideal For | Not suited to riders seeking off-road capability or high-performance cornering thrills. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
