Yamaha XMAX 125 - 2024 Specifications and Reviews
The 2024 Yamaha XSR125 is a lightweight classic-styled motorcycle ideal for new riders and commuters seeking nimble urban performance. Its fuel-injected 125cc single-cylinder engine delivers reliable everyday power with retro aesthetics, making it perfect for those who want character without complexity.
General information | |
| Category | Classic |
| Model year | 2024 |
| Model | Yamaha XSR125 Legacy |
| | |
Engine and Transmission Specifications | |
| Exhaust system | Aluminum muffler cover |
| Emission details | Euro 5 |
| Greenhouse gases | 48.7 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel consumption | 2.10 litres/100 km (47.6 km/l or 112.01 mpg) |
| Clutch | Wet, multipate |
| Transmission type | Chain (final drive) |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Ignition | TCI (Transistor Control Ignition) |
| Fuel control | Single Overhead Cams (SOHC) |
| Fuel system | Injection |
| Bore x stroke | 52.0 x 58.6 mm (2.0 x 2.3 inches) |
| Compression | 11.2:1 |
| Torque | 11.5 Nm (1.2 kgf-m or 8.5 ft.lbs) @ 8000 RPM |
| Power output | 14.8 HP (10.8 kW)) @ 10000 RPM |
| Engine type | Single cylinder, four-stroke |
| Capacity: | 124.0 ccm (7.57 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Wheels | Gold rims, wire spoked. Metzeler Karoo tyres. |
| Rear brakes | Single disc |
| Diameter | 267 mm (10.5 inches) |
| Front brakes | Single disc |
| Rear tire | 140/70-17 |
| Front tire | 110/70-17 |
| Rear wheel travel | 110 mm (4.3 inches) |
| Rear suspension | Swingarm, monoshock |
| Front wheel travel | 130 mm (5.1 inches) |
| Front suspension | Upside-down telescopic fork, Ø37 mm |
| Trail | 95 mm (3.7 inches) |
| Rake (fork angle) | 26.0° |
| Frame type | Diamond |
Physical measures and capacities | |
| Oil capacity | 1.10 litres (1.16 US quarts) |
| Fuel capacity | 10.00 litres (2.64 US gallons) |
| Wheelbase | 1330 mm (52.4 inches) |
| Ground clearance | 160 mm (6.3 inches) |
| Overall width | 805 mm (31.7 inches) |
| Overall length | 2005 mm (78.9 inches) |
| Overall height | 1090 mm (42.9 inches) |
| Seat height | 815 mm (32.1 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 140.0 kg (308.6 pounds) |
| | |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Light | LED headlight |
| Instruments | Circular LCD Meter |
| Starter | Electric |
| Color options | Historic Black |
Performance Profile & Rider Fit
14.8 hp
Peak Power
Best For
Track20%
City80%
Cornering60%
Daily Riding70%
Touring35%
Passenger30%
Rider Profile
| Best For | Note: the specifications provided are actually for the Yamaha XSR125 Legacy, not the XMAX 125 scooter named in the request, so this profile reflects that small retro-styled motorcycle instead; it suits new and beginner riders comfortably thanks to its lig |
| Purpose | Best suited as a lightweight, characterful city and commuter bike with retro scrambler styling rather than a high-speed or long-distance machine. |
| Rider Fit | Its low seat height and low 140 kg weight make it very approachable for shorter or less experienced riders to handle and paddle around at low speed. |
| Character | A charming small-capacity retro roadster that trades outright performance for style, easy manners, and everyday usability. |
| Not Ideal For | Not for riders seeking strong highway overtaking power, serious touring range, or genuine off-road capability. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
