Yamaha NMAX 155 - 2023 Specifications and Reviews
The 2023 Yamaha NMAX 155 is a practical urban scooter designed for commuters and casual riders seeking reliable daily transportation. Its 155cc liquid-cooled four-stroke engine delivers smooth, efficient performance ideal for city riding. Known for its dependable engineering and user-friendly design, the NMAX 155 excels as an affordable entry-level scooter for riders prioritizing convenience and fuel economy.
General information | |
| Category | Scooter |
| Year | 2023 |
| Model | Yamaha NMAX 155 |
| | |
Engine and Transmission Specifications | |
| Emission details | Euro 5 |
| Driveline | V-Belt Automatic |
| Clutch | Dry centrifugal |
| Transmission type | Belt (final drive) |
| Gearbox | Automatic |
| Cooling system | Liquid |
| Lubrication system | Wet sump |
| Ignition | TCI |
| Fuel control | Single Overhead Cams (SOHC) |
| Fuel system | Injection |
| Valves per Cylinder | 4 |
| Bore x Stroke | 58.0 x 58.7 mm (2.3 x 2.3 inches) |
| Compression | 11.6:1 |
| Torque | 14.4 Nm (1.5 kgf-m or 10.6 ft.lbs) @ 6000 RPM |
| Power | 12.1 HP (8.8 kW) @ 7500 RPM |
| Engine type | Single cylinder, four-stroke |
| Capacity: | 155.0 ccm (9.46 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Rear brakes | Single disc. ABS. |
| Diameter | 230 mm (9.1 inches) |
| Front brakes | Single disc. Hydraulic. ABS. |
| Rear tire | 130/70-13 |
| Front tire | 110/70-13 |
| Rear wheel travel | 85 mm (3.3 inches) |
| Rear Suspension | Unit Swing, twin shocks |
| Front wheel travel | 100 mm (3.9 inches) |
| Front Suspension | Telescopic fork |
| Trail | 92 mm (3.6 inches) |
| Rake (fork angle) | 26.0° |
| Frame type | Underbone |
| | |
Physical measures and capacities | |
| Oil capacity | 1.00 litres (1.06 US quarts) |
| Fuel capacity | 7.10 litres (1.88 US gallons) |
| Wheelbase | 1350 mm (53.1 inches) |
| Ground clearance | 135 mm (5.3 inches) |
| Overall width | 740 mm (29.1 inches) |
| Overall length | 1955 mm (77.0 inches) |
| Overall height | 1115 mm (43.9 inches) |
| Seat height | 765 mm (30.1 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 127.0 kg (280.0 pounds) |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Comments | Start and stop engine system. Smart key. |
| Carrying capacity | Underseat storage |
| Light | LED headlight |
| Instruments | LCD instruments |
| Starter | Electric |
| Color options | Milky White, Dark Petrol |
Performance Profile & Rider Fit
12.1 hp
Peak Power
Best For
Track5%
City92%
Cornering45%
Daily Riding90%
Touring25%
Passenger55%
Rider Profile
| Best For | Ideal for beginners and commuters; the twist-and-go automatic and low 765mm seat make it approachable and unintimidating for new riders. |
| Purpose | Built for urban commuting and errands. Nimble small-wheel scooter with underseat storage, great fuel economy and easy stop-and-go city manners. |
| Rider Fit | Light 127kg with a low 765mm seat and step-through underbone frame. Relaxed upright ergonomics, floorboard feet-forward stance and easy low-speed balance. |
| Character | A practical, efficient and friendly commuter scooter. Liquid-cooled 155cc single with CVT delivers smooth, fuss-free power for daily city hops. |
| Not Ideal For | Not for highway cruisers, long-distance tourers, sport riders or anyone chasing speed and outright power; also unsuited to off-road use. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
Shop This Bike
Rider Reviews
Total comments: 1
MotorcycleDB Review
The 2023 Yamaha NMAX 155 is a sleek and stylish scooter that offers a smooth and comfortable ride. Its 155cc engine provides plenty of power for city commuting, while its compact size makes it easy to maneuver through traffic. The NMAX 155 also boasts a range of features including ABS braking, LED lighting, and a digital display, making it a practical and modern choice for urban riders. Overall, the 2023 Yamaha NMAX 155 is a great option for those looking for a reliable and efficient scooter. Its stylish design, powerful engine, and advanced features set it apart from other options in its class. Whether you're a beginner rider or a seasoned commuter, the NMAX 155 offers a comfortable and enjoyable riding experience. With its combination of performance, style, and practicality, the NMAX 155 is sure to impress any rider looking for a top-notch scooter.Add a Comment
