What category is the 2019 Yamaha NMAX 125?

The 2019 Yamaha NMAX 125 has a Category of Scooter.

What is the engine size of the 2019 Yamaha NMAX 125?

The 2019 Yamaha NMAX 125 has a Capacity: of 124.7 ccm (7.61 cubic inches).

What type of engine does the 2019 Yamaha NMAX 125 have?

The 2019 Yamaha NMAX 125 has a Engine type of Single cylinder, four-stroke.

What is the engine power of the 2019 Yamaha NMAX 125?

The 2019 Yamaha NMAX 125 has a Power of 12.1 HP (8.8 kW) @ 7500 RPM.

What is the torque of the 2019 Yamaha NMAX 125?

The 2019 Yamaha NMAX 125 has a Torque of 11.7 Nm (1.2 kgf-m or 8.6 ft.lbs) @ 7500 RPM.

Is the 2019 Yamaha NMAX 125 air cooled or liquid cooled?

The 2019 Yamaha NMAX 125 has a Cooling system of Liquid.

How many gears does the 2019 Yamaha NMAX 125 have?

The 2019 Yamaha NMAX 125 has a Gearbox of Automatic.

How much does the 2019 Yamaha NMAX 125 weigh?

The 2019 Yamaha NMAX 125 has a Weight incl. oil, gas, etc of 127.0 kg (280.0 pounds).

What is the seat height of the 2019 Yamaha NMAX 125?

The 2019 Yamaha NMAX 125 has a Seat height of 765 mm (30.1 inches) If adjustable, lowest setting..

Yamaha NMAX 125 - 2019 Specifications and Reviews

Name: 2019 Yamaha NMAX 125
Brand: Yamaha
Rating: 5 (1 reviews)

The 2019 Yamaha NMAX 125 is a practical automatic scooter designed for commuters and urban riders seeking fuel efficiency and ease of use. Known for its compact yet spacious design with a low seat height, it delivers reliable performance with ABS braking on both wheels. The lightweight frame and nimble handling make it ideal for navigating city traffic.

⇄ Compare against another bike 📅 All Years

2019

Add/Upload pictures for this motorcycle

General information
Category	Scooter
Year	2019
Model	Yamaha NMAX 125

Engine and Transmission Specifications
Driveline	V-Belt Automatic
Transmission type	Belt (final drive)
Gearbox	Automatic
Cooling system	Liquid
Lubrication system	Wet sump
Ignition	Transistorised
Fuel control	Single Overhead Cams (SOHC)
Fuel system	Injection. EFI
Valves per Cylinder	4
Bore x Stroke	52.0 x 58.7 mm (2.0 x 2.3 inches)
Compression	11.2:1
Torque	11.7 Nm (1.2 kgf-m or 8.6 ft.lbs) @ 7500 RPM
Power	12.1 HP (8.8 kW) @ 7500 RPM
Engine type	Single cylinder, four-stroke
Capacity:	124.7 ccm (7.61 cubic inches)
Brakes, suspension, Frame and wheels
Rear brakes	Single disc. ABS.
Diameter	230 mm (9.1 inches)
Front brakes	Single disc. Hydraulic. ABS.
Rear tire	130/70-13
Front tire	110/70-13
Rear wheel travel	90 mm (3.5 inches)
Rear Suspension	Unit Swing, monoshock
Front wheel travel	110 mm (4.3 inches)
Front Suspension	Telescopic fork
Physical measures and capacities
Reserve fuel capacity	2.30 litres (0.61 US gallons)
Fuel capacity	6.60 litres (1.74 US gallons)
Wheelbase	1350 mm (53.1 inches)
Ground clearance	125 mm (4.9 inches)
Overall width	740 mm (29.1 inches)
Overall length	1955 mm (77.0 inches)
Overall height	1115 mm (43.9 inches)
Seat height	765 mm (30.1 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc	127.0 kg (280.0 pounds)
Other specs
Maintenance	Find parts, fluids, filters, maintenance tools and service items on eBay
Starter	Electric
Color options	Black/Grey

Performance Profile & Rider Fit

12.2 hp

Peak Power

Best For

Track3%

City95%

Cornering45%

Daily Riding90%

Touring25%

Passenger55%

Rider Profile

Best For	Ideal for beginners and commuters; twist-and-go automatic with ABS and traction control makes it approachable for new and returning riders alike.
Purpose	Built for urban commuting and errands-efficient, easy to park, with underseat storage and superb 100+ mpg economy for daily city travel.
Rider Fit	Low 765mm seat, light 131kg weight and step-through underbone frame; upright, relaxed ergonomics suit shorter and smaller riders comfortably.
Character	A practical, tech-laden 125cc scooter: smart key, stop/start, LED lights and traction control wrapped in a nimble, fuel-sipping city package.
Not Ideal For	Not for highway cruising, long-distance touring, spirited canyon carving, off-road use, or anyone wanting real speed and power.

Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.

Rider Fit Visualizer

2019 Yamaha NMAX 125 Rider Ergonomics Assessment

Your height

Inseam (optional)

Units

Calculated in your browser only - your height/inseam are never sent to our servers.

Feet:

At 765mm, a rider of 175cm with a 79cm (estimated) inseam will reach the ground with both feet flat on the 2019 Yamaha NMAX 125, with a moderate knee angle of around 100 degrees and a slightly forward riding position.

Data quality: measured. Assumes about 30mm of suspension sag once seated (a typical street-bike rule of thumb - stiffer or softer suspension will vary). This is an approximation from category-typical geometry and generic body proportions, not a measurement of this specific bike or you - sit on it before you buy.

Find bikes that fit your height →

Shop This Bike

Find Parts for the Yamaha NMAX 125 2019 Find One For Sale

Rider Reviews

Total comments: 1

MotorcycleDB Review

The 2019 Yamaha NMAX 125 is a stylish and nimble scooter that offers great performance and fuel efficiency. The 125cc engine provides plenty of power for city commuting, while the compact size and agile handling make it easy to maneuver through traffic. The NMAX 125 also features a comfortable and spacious seat, making it a great option for longer rides. With its sleek design and reliable performance, the Yamaha NMAX 125 is a top choice for riders looking for a practical and stylish urban commuting solution. Overall, the 2019 Yamaha NMAX 125 is a fantastic option for anyone in the market for a reliable and efficient scooter. Its combination of sleek design, responsive handling, and fuel-efficient engine make it a great choice for urban commuting. Whether you're navigating through city traffic or taking leisurely rides around town, the NMAX 125 delivers a smooth and enjoyable riding experience. With its practical features and impressive performance, the Yamaha NMAX 125 is a top contender in the 125cc scooter market.
