What category is the 2012 Moto Guzzi Stelvio 4V?

The 2012 Moto Guzzi Stelvio 4V has a Category of Enduro / offroad.

What is the engine size of the 2012 Moto Guzzi Stelvio 4V?

The 2012 Moto Guzzi Stelvio 4V has a Capacity: of 1151.00 ccm (70.23 cubic inches).

What type of engine does the 2012 Moto Guzzi Stelvio 4V have?

The 2012 Moto Guzzi Stelvio 4V has a Engine type of V2, four-stroke.

What is the engine power of the 2012 Moto Guzzi Stelvio 4V?

The 2012 Moto Guzzi Stelvio 4V has a Power of 103.26.

What is the torque of the 2012 Moto Guzzi Stelvio 4V?

The 2012 Moto Guzzi Stelvio 4V has a Torque of 108.00 Nm (11.0 kgf-m or 79.7 ft.lbs) @ 6400.

Is the 2012 Moto Guzzi Stelvio 4V air cooled or liquid cooled?

The 2012 Moto Guzzi Stelvio 4V has a Cooling system of Oil & air.

How many gears does the 2012 Moto Guzzi Stelvio 4V have?

The 2012 Moto Guzzi Stelvio 4V has a Gearbox of 6-speed.

How much does the 2012 Moto Guzzi Stelvio 4V weigh?

The 2012 Moto Guzzi Stelvio 4V has a Weight incl. oil, gas, etc of 251.0 kg (553.4 pounds).

What is the seat height of the 2012 Moto Guzzi Stelvio 4V?

The 2012 Moto Guzzi Stelvio 4V has a Seat height of 840 mm (33.1 inches) If adjustable, lowest setting..

Moto Guzzi Stelvio 4V - 2012 Specifications and Reviews

Name: 2012 Moto Guzzi Stelvio 4V
Brand: Moto Guzzi

The 2012 Moto Guzzi Stelvio 4V is a large-displacement adventure bike designed for experienced riders seeking genuine off-road capability combined with long-distance touring comfort. Its 1151cc V-twin engine delivers responsive power and strong torque ideal for varied terrain, while the robust construction and refined handling make it well-suited for exploration across diverse landscapes. Known for blending Italian engineering heritage with practical adventure-touring versatility, the Stelvio 4V appeals to adventure riders prioritizing substance over fashion.

⇄ Compare against another bike 📅 All Years

2012

❮❯

Add/Upload pictures for this motorcycle

General information
Category	Enduro / offroad
Year	2012
Model	Moto Guzzi Stelvio 4V

Engine and Transmission Specifications
Exhaust system	Stainless steel two-into-one
Emission details	3-way catalysed with Lambda probe. Euro 3.
Driveline	Compact reactive cardan shaft drive system called CA.R.C.; double joint and floating bevel gear pair, ratio 12/44 = 1 : 3.666
Clutch	Single-disc with integrated anti-vibration buffer
Transmission type,final drive	Shaft drive (cardan)
Gearbox	6-speed
Cooling system	Oil & air
Ignition	Multipoint sequential electronic ignition, Magneti Marelli
Fuel control	OHV
Fuel system	Injection
Valves per cylinder	2
Bore x stroke	95.0 x 81.2 mm (3.7 x 3.2 inches)
Compression	11.0:1
Torque	108.00 Nm (11.0 kgf-m or 79.7 ft.lbs) @ 6400
Power	103.26
Engine details	90° V-twin.
Engine type	V2, four-stroke
Capacity:	1151.00 ccm (70.23 cubic inches)

Brakes, suspension, Frame and wheels
Wheels	Tubeless with spokes
Rear brakes diameter	282 mm (11.1 inches)
Rear brakes	Single disc. Single fixed stainless steel disc, floating caliper with 2 parallel pistons.
Front brakes diameter	320 mm (12.6 inches)
Front brakes	Double disc. Stainless steel wave discs, radial calipers with 4 opposed pistons.
Rear tyre dimensions	180/55-R17
Front tyre dimensions	110/80-R19
Rear suspension travel	155 mm (6.1 inches)
Rear suspension	Progressive single swingarm, fully adjustable monoshock with separate gas reservoir (spring preload and hydraulic for rebound and compression).
Front suspension travel	170 mm (6.7 inches)
Front suspension	Fork with 50mm inverted stems, fully adjustable (spring preload and hydraulic compression and rebound damping)
Trail	125 mm (4.9 inches)
Rake (fork angle)	27.0°
Frame type	Tubular in high-strength steel with integrated engine
Physical measures and capacities
Reserve fuel capacity	4.50 litres (1.19 gallons)
Fuel capacity	18.00 litres (4.76 gallons)
Wheelbase	1,535 mm (60.4 inches)
Ground clearance	210 mm (8.3 inches)
Overall width	1,025 mm (40.4 inches)
Overall length	2,250 mm (88.6 inches)
Overall height	1,475 mm (58.1 inches)
Seat height	840 mm (33.1 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc	251.0 kg (553.4 pounds)
Other specs
Maintenance	Find parts, fluids, filters, maintenance tools and service items on eBay
Color options	Guzzi Black
Electrical	12 V 18 Ah battery
Starter	Electric

Performance Profile & Rider Fit

103.3 hp

Peak Power

0-60 mph

Best For

Track35%

City55%

Cornering60%

Daily Riding68%

Touring85%

Passenger75%

Rider Profile

Best For	Best suited to riders with at least some prior big-bike experience, given its 251kg weight and tall 840mm seat height.
Purpose	Designed as a road-biased adventure tourer for long-distance shaft-drive touring rather than serious offroad work.
Rider Fit	Taller and stronger riders will find it easier to manage at a stop due to its weight and seat height, though the low center of mass from the boxer-style twin helps balance.
Character	A characterful, torque-rich V-twin adventure bike with shaft drive smoothness and a distinctive Moto Guzzi personality rather than outright sharpness or speed.
Not Ideal For	Not ideal for riders seeking a nimble, lightweight dirt-focused enduro or a track-day performance machine.

Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.

Rider Fit Visualizer

2012 Moto Guzzi Stelvio 4V Rider Ergonomics Assessment

Your height

Inseam (optional)

Units

Calculated in your browser only - your height/inseam are never sent to our servers.

Feet:

At 840mm, a rider of 175cm with a 79cm (estimated) inseam will reach the ground with balls of both feet on the 2012 Moto Guzzi Stelvio 4V, with a cramped knee angle of around 70 degrees and a slightly forward riding position.

Data quality: measured. Assumes about 30mm of suspension sag once seated (a typical street-bike rule of thumb - stiffer or softer suspension will vary). This is an approximation from category-typical geometry and generic body proportions, not a measurement of this specific bike or you - sit on it before you buy.
