What category is the 2009 Moto Guzzi Bellagio?

The 2009 Moto Guzzi Bellagio has a Category of Custom / cruiser.

What is the engine size of the 2009 Moto Guzzi Bellagio?

The 2009 Moto Guzzi Bellagio has a Capacity: of 935.60 ccm (57.09 cubic inches).

What type of engine does the 2009 Moto Guzzi Bellagio have?

The 2009 Moto Guzzi Bellagio has a Engine type of V2.

What is the engine power of the 2009 Moto Guzzi Bellagio?

The 2009 Moto Guzzi Bellagio has a Power of 73.75.

What is the torque of the 2009 Moto Guzzi Bellagio?

The 2009 Moto Guzzi Bellagio has a Torque of 78.00.

Is the 2009 Moto Guzzi Bellagio air cooled or liquid cooled?

The 2009 Moto Guzzi Bellagio has a Cooling system of Air.

How many gears does the 2009 Moto Guzzi Bellagio have?

The 2009 Moto Guzzi Bellagio has a Gearbox of 6-speed.

How much does the 2009 Moto Guzzi Bellagio weigh?

The 2009 Moto Guzzi Bellagio has a Dry weight of 224.0 kg (493.8 pounds).

What is the seat height of the 2009 Moto Guzzi Bellagio?

The 2009 Moto Guzzi Bellagio has a Seat height of 780 mm (30.7 inches) If adjustable, lowest setting..

Moto Guzzi Bellagio - 2009 Specifications and Reviews

Name: 2009 Moto Guzzi Bellagio
Brand: Moto Guzzi
Rating: 4 (1 reviews)

The 2009 Moto Guzzi Bellagio is a cruiser designed for riders seeking classic Italian styling with modern reliability and touring capability. Powered by a 936cc V-twin engine producing 74 horsepower, it combines relaxed ergonomics with sophisticated fuel injection and electronic ignition. Best known for its retro aesthetic and comfortable mid-range torque delivery, the Bellagio appeals to experienced cruiser enthusiasts wanting an alternative to Japanese and American heavyweights.

⇄ Compare against another bike 📅 All Years

2009

Add/Upload pictures for this motorcycle

General information
Category	Custom / cruiser
Year	2009
Model	Moto Guzzi Bellagio
Engine and Transmission Specifications
Clutch	Dry mechanically operated twin plate
Transmission typefinal drive	Shaft drive (cardan)
Gearbox	6-speed
Cooling system	Air
Lubrication system	Helicoidal gears, ratio 24/35 = 1 : 1.458
Starter	Electric
Ignition	Digital electronic with Magneti Marelli IAW 15RC inductive discharge
Valves per cylinder	2
Fuel system	Injection. Multipoint sequential electronic injection, Magneti Marelli IAW phased, alfa-n system; 2 40 mm throttle bodies with Weber IW 031 injectors
Bore x stroke	95.0 x 66.0 mm (3.7 x 2.6 inches)
Compression	10.0:1
Torque	78.00
Power	73.75
Stroke	4
Engine type	V2
Capacity:	935.60 ccm (57.09 cubic inches)
Physical measures and capacities
Wheelbase	1,570 mm (61.8 inches)
Ground clearance	150 mm (5.9 inches)
Overall width	890 mm (35.0 inches)
Overall length	2,270 mm (89.4 inches)
Overall height	1,310 mm (51.6 inches)
Seat height	780 mm (30.7 inches) If adjustable, lowest setting.
Dry weight	224.0 kg (493.8 pounds)

Moto Guzzi Bellagio dimensions and frame
Exhaust system	Maximum Maximum power
Rear brakes diameter	282 mm (11.1 inches)
Rear brakes	Single disc. Fixed stainless steel disc, floating Brembo calipers with 2 parallel pistons.
Front brakes diameter	320 mm (12.6 inches)
Front brakes	Double disc. Stainless steel discs, floating Brembo calipers with 2 parallel pistons.
Front tyre dimensions	120/70-18
Rear suspension travel	330 mm (13.0 inches)
Rear suspension	Single swingarm with progressive action and ndash
Front suspension travel	330 mm (13.0 inches)
Front suspension	Marzocchi 45 mm adjustable front forks
Trail	138 mm (5.4 inches)
Rake (fork angle)	28.0°
Frame type	Very rigid high tensile steel tubular twin cradle
Speed and acceleration
Power/weight ratio	0.3292 HP/kg

Other specs
Maintenance	Find parts, fluids, filters, maintenance tools and service items on eBay
Color options	Black
Reserve fuel capacity	4.00 litres (1.06 gallons)
Fuel capacity	19.00 litres (5.02 gallons)

Performance Profile & Rider Fit

75 hp

Peak Power

4.8s

0-60 mph

Best For

Track20%

City55%

Cornering50%

Daily Riding65%

Touring60%

Passenger55%

Rider Profile

Best For	Suits riders with some prior experience who want a torquey, laid-back V-twin cruiser rather than an outright beginner bike.
Purpose	Built for relaxed cruising and boulevard riding with distinctive Moto Guzzi V-twin character rather than outright performance.
Rider Fit	A moderate seat height and manageable weight make it accessible, though the mass and low-slung stance require confident low-speed handling.
Character	An understated, mechanically charismatic cruiser that rewards riders who enjoy shaft-drive V-twin feel over raw speed.
Not Ideal For	Not a good fit for riders seeking sharp sportbike agility, off-road capability, or high-speed track performance.

Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.

Rider Fit Visualizer

2009 Moto Guzzi Bellagio Rider Ergonomics Assessment

Your height

Inseam (optional)

Units

Calculated in your browser only - your height/inseam are never sent to our servers.

Feet:

At 780mm, a rider of 175cm with a 79cm (estimated) inseam will reach the ground with both feet flat on the 2009 Moto Guzzi Bellagio, with a cramped knee angle of around 85 degrees and an upright riding position.

Data quality: measured. Assumes about 30mm of suspension sag once seated (a typical street-bike rule of thumb - stiffer or softer suspension will vary). This is an approximation from category-typical geometry and generic body proportions, not a measurement of this specific bike or you - sit on it before you buy.
