KTM 690 Enduro R - 2024 Specifications and Reviews
The 2024 KTM 790 Adventure is a versatile middleweight adventure bike designed for riders seeking a capable all-rounder for both on-road and off-road exploration. Its 799cc twin-cylinder engine delivers smooth power and strong torque across the rev range, making it equally at home on highways and challenging terrain. Known for its agile handling, upright ergonomics, and proven reliability, it excels as an accessible adventure platform for experienced and intermediate riders alike.
General information | |
| Type | Allround |
| Year of manufacture | 2024 |
| Model name | KTM 790 Adventure |
| | |
Engine and Transmission Specifications | |
| Emission details | Euro 5 |
| Greenhouse gases | 97.2 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel consumption | 4.19 litres/100 km (23.9 km/l or 56.14 mpg) |
| Clutch | PASCâ„¢ antihopping clutch, mechanically operated |
| Transmission type | Chain (final drive) |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Lubrication system | Forced oil lubrication with 2 oil pumps |
| Ignition | Bosch EMS with RBW |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Fuel system | Injection |
| Bore x stroke | 88.0 x 65.7 mm (3.5 x 2.6 inches) |
| Torque | 87.0 Nm (8.9 kgf-m or 64.2 ft.lbs) |
| Output | 93.9 HP (68.5 kW)) |
| Type of engine | Twin, four-stroke |
| Capacity: | 799.0 ccm (48.75 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Wheels | Maxxis Supermaxx ST tires |
| Rear brakes | Single disc. ABS |
| Diameter | 320 mm (12.6 inches) |
| Front brakes | Double disc. ABS. 4 piston caliper. |
| Rear wheel travel | 200 mm (7.9 inches) |
| Rear suspension | WP APEX - Monoshock |
| Front wheel travel | 200 mm (7.9 inches) |
| Front suspension | WP APEX 43 |
| Rake (fork angle) | 25.9° |
| Frame type | Chromium-Molybdenum-Steel frame using the engine as stressed element, powder coated |
Physical measures and capacities | |
| Fuel capacity | 20.00 litres (5.28 US gallons) |
| Wheelbase | 1475 mm (58.1 inches) |
| Ground clearance | 233 mm (9.2 inches) |
| Alternate seat height | 860 mm (33.9 inches) If adjustable, highest setting. |
| Seat height | 840 mm (33.1 inches) If adjustable, lowest setting. |
| Power/weight ratio | 0.4717 HP/kg |
| Dry weight | 199.0 kg (438.7 pounds) |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Comments | Windscreen. |
| Light | LED headlight |
| Starter | Electric |
| Color options | White/orange/black |
Performance Profile & Rider Fit
78 hp
Peak Power
4.2s
0-60 mph
Best For
Track35%
City45%
Cornering75%
Daily Riding40%
Touring40%
Passenger15%
Rider Profile
| Best For | Best suited to intermediate-to-experienced riders who are comfortable with a tall, light, powerful single-cylinder machine that demands active input. |
| Purpose | Built primarily as a big-bore enduro weapon for serious off-road riding, trail exploration, and technical terrain, with light road use as a secondary role. |
| Rider Fit | The tall 935mm seat height and 152kg dry-oriented weight favor taller or more athletic riders who can confidently manage standing, shifting body weight, and paddling the bike at low speed. |
| Character | A raw, torquey big single with a lightweight chassis rewards decisive, engaged riding and punishes hesitation, giving it a focused, no-nonsense personality. |
| Not Ideal For | Not a good fit for riders wanting plush comfort, pillion-friendly touring, or a low-effort commuter experience. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
