What category is the 2027 KTM 500 EXC F?

The 2027 KTM 500 EXC F has a Category of Enduro / offroad.

What is the engine size of the 2027 KTM 500 EXC F?

The 2027 KTM 500 EXC F has a Capacity: of 510.9 ccm (31.18 cubic inches).

How many gears does the 2027 KTM 500 EXC F have?

The 2027 KTM 500 EXC F has a Gearbox of 6-speed.

KTM 500 EXC F - 2027 Specifications and Reviews

Name: 2027 KTM 500 EXC F
Brand: KTM

The KTM 500 EXC-F continues for 2027 as the largest-displacement model in KTM's four-stroke enduro range, powered by a 510.9cc single-cylinder engine through a 6-speed gearbox and Brembo-actuated wet clutch. It shares its chromoly steel frame, WP XACT-USD fork, and WP Xplor PDS shock with the rest of the EXC-F lineup, at a claimed 108.4 kg dry weight and 963mm seat height. Built for serious enduro and technical off-road riding, its larger engine trades some agility for extra low-end torque.

⇄ Compare against another bike 📅 All Years

2027

2026

❮❯

Add/Upload pictures for this motorcycle

General information
Color Options	Orange/grey/black/
Category	Enduro / offroad
Year	2027
Model	KTM 500 EXC F

Engine and Transmission Specifications
Starting	Electric
Emission	84.0 CO2 g/km. (CO2 - Carbon dioxide emission)
Fuel Consumption	3.62 litres/100 km (27.6 km/l or 64.98 mpg)
Clutch	Wet, DDS multi-disc clutch, Brembo hydraulics
Final Drive	Chain (final drive)
Gearbox	6-speed
Cooling System	Liquid
Ignition	Keihin EMS
Fuel Control	Single Overhead Cams (SOHC)
Induction	Injection. Keihin EFI, throttle body 42 mm
Bore x Stroke	95.0 x 72.0 mm (3.7 x 2.8 inches)
Compression Ratio	12.8:1
Engine Type	Single cylinder, four-stroke
Capacity:	510.9 ccm (31.18 cubic inches)

Physical measures and capacities
Fuel Capacity	8.50 litres (2.25 US gallons)
Wheelbase	1489 mm (58.6 inches)
Ground Clearance	347 mm (13.7 inches)
Seat Height	963 mm (37.9 inches) If adjustable, lowest setting.
Dry Weight	108.4 kg (239.0 pounds)
KTM 500 EXC F dimensions and frame
Rear Brakes	Single disc
Brake Disc Diameter	220 mm (8.7 inches)
Front Brakes	Single disc
Rear Tyre	140/80-18
Front Tyre	90/90-21
Rear Wheel Travel	310 mm (12.2 inches)
Rear Suspension	WP XPLOR shock absorber with PDS
Front Wheel Travel	300 mm (11.8 inches)
Front Suspension	WP XACT-USD, Ã˜ 48 mm
Frame	Central double-cradle-type 25CrMo4 steel. Aluminum-reinforced polyamide subframe.
Other specs
Maintenance	Find parts, fluids, filters, maintenance tools and service items on eBay
Update specs	Report missing specs or required updates.
Electrical	2Ah lithium-ion battery
Rake (fork angle)	26.1Â°
Exhaust system	Aluminum
Driveline	520 X-ring chain

Performance Profile & Rider Fit

Best For

Track25%

City20%

Cornering70%

Daily Riding25%

Touring30%

Passenger5%

Rider Profile

Best For	This bike suits experienced off-road riders who are comfortable with a tall, light, powerful enduro machine that demands active riding skills.
Purpose	Built for serious enduro and technical off-road riding, including trails, hillclimbs, and competition-level terrain, not for street commuting or highway travel.
Rider Fit	The tall 963 mm seat height and minimal weight favor taller, fit riders who can manage a top-heavy stance at low speed and stand for extended technical sections.
Character	A raw, high-performance thumper with strong torque and race-bred suspension that rewards decisive, aggressive riding over technical obstacles.
Not Ideal For	Not a good fit for short riders, beginners, passengers, or anyone wanting a comfortable, low-maintenance daily or touring bike.

Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.

Rider Fit Visualizer

2027 KTM 500 EXC F Rider Ergonomics Assessment

Your height

Inseam (optional)

Units

Calculated in your browser only - your height/inseam are never sent to our servers.

Feet:

At 963mm, a rider of 175cm with a 79cm (estimated) inseam will not reach the ground comfortably on the 2027 KTM 500 EXC F, with a cramped knee angle of around 85 degrees and an upright riding position.

Data quality: measured. Assumes about 30mm of suspension sag once seated (a typical street-bike rule of thumb - stiffer or softer suspension will vary). This is an approximation from category-typical geometry and generic body proportions, not a measurement of this specific bike or you - sit on it before you buy.
