Harley-Davidson FXDWG Dyna Wide Glide - 2012 Specifications and Reviews
The 2012 Harley-Davidson FXDWG Dyna Wide Glide is a custom cruiser designed for riders seeking classic styling with modern reliability. Known for its stretched front end, wide stance, and distinctive appearance, it delivers accessible power and handling in a mid-weight package. Best suited for cruiser enthusiasts who value character and customization potential over sportiness.
General information | |
| Category | Custom / cruiser |
| Year | 2012 |
| Model | Harley-Davidson FXDWG Dyna Wide Glide |
Engine and Transmission Specifications | |
| Greenhouse gases | 129.9 CO |
| Fuel consumption | 5.60 litres/100 km (17.9 km/l or 42.00 mpg) |
| Driveline | Primary Drive Chain, 34/46 ratio. Final Drive Belt, 32/66 ratio. |
| Clutch | Multi-plate with diaphragm spring in oil bath |
| Transmission type,final drive | Belt |
| Gearbox | 6-speed |
| Cooling system | Air |
| Lubrication system | Pressurized, dry-sump |
| Fuel control | DOHC |
| Fuel system | Injection. Electronic Sequential Port Fuel Injection (ESPFI) |
| Valves per cylinder | 2 |
| Bore x stroke | 98.4 x 111.3 mm (3.9 x 4.4 inches) |
| Compression | 9.6:1 |
| Torque | 135.60 Nm (13.8 kgf-m or 100.0 ft.lbs) @ 3500 |
| Engine details | Air-cooled, Twin Cam 103. Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder |
| Engine type | V2, four-stroke |
| Capacity: | 1687.97 ccm (103.00 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Wheels | Black, Laced Steel |
| Rear brakes diameter | 292 mm (11.5 inches) |
| Rear brakes | Single disc. 2-piston torque-free floating. Optional ABS. |
| Front brakes diameter | 300 mm (11.8 inches) |
| Front brakes | Single disc. 4-piston fixed. Optional ABS. |
| Rear tyre dimensions | 180/60-B17 |
| Front tyre dimensions | 80/90-H21 |
| Rear suspension travel | 79 mm (3.1 inches) |
| Rear suspension | Coil-over shock. Mild steel, rectangular tube sections, stamped junctions; MIG welded swingarm. |
| Front suspension travel | 127 mm (5.0 inches) |
| Front suspension | 49 mm with polished aluminum fork triple clamp and dual-rate springs |
| Trail | 132 mm (5.2 inches) |
| Rake (fork angle) | 34.0° |
| Frame type | Mild steel, tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded |
Physical measures and capacities | |
| Oil capacity | 2.80 litres (0.18 quarts) |
| Fuel capacity | 17.79 litres (4.70 gallons) |
| Wheelbase | 1,735 mm (68.3 inches) |
| Ground clearance | 107 mm (4.2 inches) |
| Overall length | 2,388 mm (94.0 inches) |
| Seat height | 648 mm (25.5 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 303.0 kg (668.0 pounds) |
| Dry weight | 294.8 kg (650.0 pounds) |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Color options | Vivid Black, Vivid Black with Flames, Big Blue Pearl with Flames, Ember Red Sunglo with Flames |
| Factory warranty | 2 years, unlimited mileage. |
| Seat | Low solo seat with separate passenger pillion |
| Electrical | Sealed, maintenance-free, 12V, 19-amp/hour, 270 cca |
| Light | 55-watt low beam, 60-watt high beam |
| Instruments | Tank-mounted electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, RPM/Gear display, fuel gauge with low fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicator lights, 6-speed indicator light |
Performance Profile & Rider Fit
Best For
Rider Profile
| Best For | Best suited to riders who already have some experience handling a heavy, torque-driven cruiser at low speeds. |
| Purpose | Built for laid-back boulevard cruising and show-worthy styling rather than outright speed or distance-eating touring. |
| Rider Fit | The low seat height and wide, raked-out front end make it easy to plant feet at a stop, but the stretched stance and wide bars demand some arm and shoulder reach. |
| Character | A classic factory custom with a big air-cooled V-twin rumble, chopper-inspired styling, and relaxed, torque-heavy delivery over high-rev performance. |
| Not Ideal For | Not the right choice for riders seeking sharp cornering agility, off-road capability, or long-haul touring comfort. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
⚠ Safety Recalls (1)
Harley-Davidson Motor Company (Harley-Davidson) is recalling certain model year 2012 FXST103, FLSTC, FLSTC103, FLSTF, FLSTF103, FXDL, FXDWG, FXDWG103, FXDC, FXDB, FLSTN, FLSTN103, FLSTC103Shrine, FLSTFB, FLSTFB103, FXS, FXS103, FLS, FLS103, FLD, FLD103, FXDF, and FXDF103 Dyna and Softail motorcycles manufactured August 22, 2011, through February 24, 2012. In the affected motorcycles, the threads for the brake line banjo bolt in the front brake master cylinder may corrode.
Risk: If the threads corrode, a sudden loss of brake fluid could result, causing a loss of the front brakes, and increasing the risk of a crash.
Remedy: Harley-Davidson will notify owners, and dealers will flush and inspect the front brake master cylinder and, if necessary, replace the master cylinder, free of charge. The recall is expected to begin on January 22, 2015. Owners may contact Harley-Davidson customer service at 1-800-258-2464. Harley-Davidson's number for this recall is 0163 and 0164.
Source: NHTSA. View all Harley-Davidson recalls →
