Can-Am Outlander Pro HD5 - 2025 Specifications and Reviews
The 2025 Can-Am Outlander Pro HD5 is a versatile mid-size ATV designed for recreational riders seeking reliable off-road performance and everyday usability. Known for its comfortable seating, strong cargo capacity with front and rear racks, and user-friendly 4.5-inch digital display, it balances capability with accessibility. The electric start and 19.3-liter fuel tank provide convenience for extended trail adventures.
2025
General information | |
| Color Options | Beige, green |
| Price | US$ 7749. MSRP depends on country, taxes, accessories, etc. |
| Category | ATV |
| Model | Can-Am Outlander Pro HD5 |
Engine and Transmission Specifications | |
| Starting | Electric |
| Clutch | CVT with work calibration Extra low L / H / N / R / P |
| Final Drive | Belt (final drive) |
| Gearbox | Automatic |
| Cooling System | Liquid |
| Induction | Injection |
| Max Torque | 50.2 Nm (5.1 kgf-m or 37.0 ft.lbs) |
| Max Power | 40.0 HP (29.2 kW)) |
| Engine Details | Rotax ACE engine |
| Capacity: | 650.0 ccm (39.66 cubic inches) |
| | |
Physical measures and capacities | |
| Fuel Capacity | 19.30 litres (5.10 US gallons) |
| Wheelbase | 1346 mm (53.0 inches) |
| Ground Clearance | 330 mm (13.0 inches) |
| Overall Width | 1239 mm (48.8 inches) |
| Overall Length | 2284 mm (89.9 inches) |
| Overall Height | 1225 mm (48.2 inches) |
| Seat Height | 980 mm (38.6 inches) If adjustable, lowest setting. |
| Power/Weight Ratio | 0.1102 HP/kg |
| Dry Weight | 363.0 kg (800.3 pounds) |
Can-Am Outlander Pro HD5 dimensions and frame | |
| Rear Brakes | Single disc. Hydraulic twin-piston calipers |
| Brake Disc Diameter | 214 mm (8.4 inches) |
| Front Brakes | Double disc. Hydraulic twin-piston calipers |
| Rear Tyre | 26/8-12 |
| Front Tyre | 26/8-12 |
| Rear Wheel Travel | 260 mm (10.2 inches) |
| Rear Suspension | Double A-Arm, twin tube |
| Front Wheel Travel | 248 mm (9.8 inches) |
| Front Suspension | Double A-Arm, twin shocks |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Update specs | Report missing specs or required updates. |
| Comments | Various options. |
| Warranty | 6 months |
| Carrying Capacity | Front and rear racks |
| Lighting | LED lights |
| Instruments | 4.5 in. digital display |
| Driveline | Selectable 2WD / 4WD with Visco-Lok auto-locking front differential |
| Engine type | Single cylinder, four-stroke |
| Model year | 2025 |
Performance Profile & Rider Fit
40 hp
Peak Power
Best For
Track5%
City15%
Cornering40%
Daily Riding50%
Touring35%
Passenger10%
Rider Profile
| Best For | Suited to riders from novice to experienced who need a dependable work-oriented ATV rather than a high-performance machine. |
| Purpose | Built primarily as a utility and farm/ranch workhorse, with selectable 4WD, front and rear racks, and long-travel suspension for hauling and rough terrain rather than recreational speed. |
| Rider Fit | A large, heavy single-seat quad that demands moderate physical effort to muscle through tight trails but rewards stability at low speeds and over rough ground. |
| Character | A no-nonsense, torque-focused workhorse defined by its Rotax single-cylinder engine, CVT automatic gearbox, and robust chassis rather than outright performance. |
| Not Ideal For | Not for riders seeking speed, cornering agility, or a passenger-friendly, road-going touring experience. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
