CH Racing WSM 50 - 2010 Specifications and Reviews
The 2010 CH Racing WSM 50 is a liquid-cooled super motard designed for entry-level riders seeking nimble urban and light off-road performance. Its lightweight 50cc two-stroke engine delivers accessible power while the upside-down forks and progressive rear suspension provide confident handling characteristics typical of the super motard category.
2010
Engine and Transmission Specifications | |
| Transmission type,final drive | Chain |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Fuel system | Carburettor. PHBN 16 |
| Top speed | 45.0 km/h (28.0 mph) |
| Engine type | Single cylinder, two-stroke |
| Capacity: | 49.70 ccm (3.03 cubic inches) |
| Category | Super motard |
| Year | 2010 |
| Model | CH Racing WSM 50 |
Brakes, suspension, Frame and wheels | |
| Rear brakes diameter | 200 mm (7.9 inches) |
| Rear brakes | Single disc |
| Front brakes diameter | 260 mm (10.2 inches) |
| Front brakes | Single disc |
| Rear tyre dimensions | 130/70-17 |
| Front tyre dimensions | 100/80-17 |
| Rear suspension | Progressive unitrac type with single hydraulic shock absorber |
| Front suspension | MARZOCCHI upside-down telescopic hydraulic fork - black color |
| | |
Physical measures and capacities | |
| Fuel capacity | 8.00 litres (2.11 gallons) |
| Wheelbase | 1,375 mm (54.1 inches) |
| Ground clearance | 300 mm (11.8 inches) |
| Overall length | 1,990 mm (78.3 inches) |
| Overall height | 1,160 mm (45.7 inches) |
| Weight incl. oil, gas, etc | 100.0 kg (220.5 pounds) |
| Dry weight | 92.0 kg (202.8 pounds) |
| | |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Color options | Red/white. |
| Starter | Kick |
Performance Profile & Rider Fit
28 mph
Top Speed
Best For
Track30%
City55%
Cornering60%
Daily Riding35%
Touring10%
Passenger10%
Rider Profile
| Best For | This is a small-displacement moped-class machine best suited to beginners or younger riders, likely restricted by its 45 km/h top speed to a learner or licensing category. |
| Purpose | Styled as a mini supermotard with inverted forks and disc brakes, it's designed for playful, low-speed urban fun rather than genuine performance riding. |
| Rider Fit | Its very light weight of around 100 kg and low seat height make it extremely easy and unintimidating to handle for smaller or less experienced riders. |
| Character | It has the aggressive supermotard look of a much bigger bike but delivers only moped-level performance, making it more of a fun style statement than a serious tool. |
| Not Ideal For | This is not suitable for highway travel, touring, carrying a passenger long distance, or anyone seeking real speed or power. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
