Bimota KB4 RC - 2024 Specifications and Reviews
The 2024 Bimota Tesi H2 is a cutting-edge sport motorcycle powered by Kawasaki's supercharged 998cc inline-four engine producing 228 horsepower. Built for experienced riders seeking extreme performance and advanced technology, it combines hub-center steering with sophisticated fuel injection for uncompromising track capability and precision handling.
2024
General information | |
| Price as new | Do you know this bike?Click here to rate it. We miss 2 votes to show the rating. |
| Category | Sport |
| Year | 2024 |
| Model | Bimota Tesi H2 |
Engine and Transmission Specifications | |
| Emission details | Euro 4 |
| Driveline | Constant mesh |
| Clutch | Wet multi-disc, manual |
| Transmission type | Chain (final drive) |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Lubrication system | Wet sump |
| Ignition | Digital |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Fuel system | Injection. DFI®: 50 mm throttle bodies (4) with dual injection |
| Valves per cylinder | 4 |
| Bore x stroke | 76.0 x 55.0 mm (3.0 x 2.2 inches) |
| Compression | 8.5:1 |
| Torque | 141.0 Nm (14.4 kgf-m or 104.0 ft.lbs) @ 11000 RPM |
| Power | 228.0 HP (166.4 kW)) @ 11500 RPM |
| Engine details | Kawaski H2 engine |
| Engine type | In-line four, four-stroke |
| Capacity: | 998.0 ccm (60.90 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Wheels | Black, 5-spoke |
| Rear brakes | Single disc. ABS |
| Diameter | 330 mm (13.0 inches) |
| Front brakes | Double disc. ABS. Brembo Stylema opposed 4-piston calipers. |
| Rear tire | 200/55-ZR17 |
| Front tire | 120/70-R17 |
| Rear wheel travel | 130 mm (5.1 inches) |
| Rear suspension | Billet aluminum alloy swingarm |
| Front wheel travel | 110 mm (4.3 inches) |
| Front suspension | Billet aluminum alloy swingarm |
| Trail | 117 mm (4.6 inches) |
| Rake (fork angle) | 21.3° |
| Frame type | Aluminum and carbon-fiber |
Physical measures and capacities | |
| Oil capacity | 5.00 litres (5.28 US quarts) |
| Fuel capacity | 17.00 litres (4.49 US gallons) |
| Wheelbase | 1445 mm (56.9 inches) |
| Ground clearance | 140 mm (5.5 inches) |
| Overall width | 770 mm (30.3 inches) |
| Overall length | 2074 mm (81.7 inches) |
| Overall height | 1155 mm (45.5 inches) |
| Seat height | 840 mm (33.1 inches) If adjustable, lowest setting. |
| Power/weight ratio | 1.1013 HP/kg |
| Dry weight | 207.0 kg (456.4 pounds) |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Comments | Windscreen |
| Instruments | TFT instrumentation |
| Starter | Electric |
| Color options | Red/white/grey/green, black/red/grey |
Performance Profile & Rider Fit
228 hp
Peak Power
2.6s
0-60 mph
Best For
Track95%
City30%
Cornering93%
Daily Riding25%
Touring25%
Passenger10%
Rider Profile
| Best For | Note: specs given are for the Bimota Tesi H2, not the KB4 RC, but this profile is built from that data; this is a machine strictly for expert, highly experienced riders only. |
| Purpose | Built as an exotic, hypersport-level exhibition of engineering, blending supercharged Kawasaki H2 power with Bimota's exotic hub-center steering front end for extreme performance and track-focused precision. |
| Rider Fit | Demands a fit, strong rider comfortable with an aggressive forward-leaning stance, high footpegs, and the physical intensity of managing 228 hp with minimal comfort accommodations. |
| Character | A rare, boutique hypersport machine for riders who want cutting-edge chassis technology, jaw-dropping acceleration, and exclusivity over practicality. |
| Not Ideal For | Not suitable for beginners, commuters, passengers, or anyone seeking comfort, storage, or all-weather everyday usability. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
