General information | |
| Category | Trial |
| Year | 2006 |
| Model | Beta Rev-80 |
Engine and Transmission Specifications | |
| Clutch | Wet multi-disc |
| Transmission typefinal drive | Chain |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Lubrication system | Fuel mix 1.5% |
| Ignition | Electronic |
| Fuel system | Carburettor. Dell´ orto PHBG 21 |
| Bore x stroke | 48.0 x 44.0 mm (1.9 x 1.7 inches) |
| Compression | 14.7:1 |
| Stroke | 2 |
| Engine type | Single cylinder |
| Capacity: | 79.60 ccm (4.86 cubic inches) |
| | |
Physical measures and capacities | |
| Wheelbase | 1,230 mm (48.4 inches) |
| Ground clearance | 345 mm (13.6 inches) |
| Overall width | 815 mm (32.1 inches) |
| Overall length | 1,925 mm (75.8 inches) |
| Overall height | 1,110 mm (43.7 inches) |
| Dry weight | 64.0 kg (141.1 pounds) |
| | |
Beta Rev-80 dimensions and frame | |
| Rear brakes diameter | 150 mm (5.9 inches) |
| Rear brakes | Single disc |
| Front brakes diameter | 175 mm (6.9 inches) |
| Front brakes | Single disc |
| Rear suspension travel | 150 mm (5.9 inches) |
| Rear suspension | Monoshock |
| Front suspension travel | 160 mm (6.3 inches) |
| Front suspension | Hydraulic fork |
| Frame type | Steel |
Speed and acceleration | |
| Reserve fuel capacity | 0.50 litres (0.13 gallons) |
| Fuel capacity | 2.50 litres (0.66 gallons) |
