What category is the 2023 TM Racing EN 530 Fi 4T?

The 2023 TM Racing EN 530 Fi 4T has a Category of Enduro / offroad.

What is the engine size of the 2023 TM Racing EN 530 Fi 4T?

The 2023 TM Racing EN 530 Fi 4T has a Capacity: of 528.0 ccm (32.22 cubic inches).

What type of engine does the 2023 TM Racing EN 530 Fi 4T have?

The 2023 TM Racing EN 530 Fi 4T has a Engine type of Single cylinder, four-stroke.

Is the 2023 TM Racing EN 530 Fi 4T air cooled or liquid cooled?

The 2023 TM Racing EN 530 Fi 4T has a Cooling system of Liquid.

How many gears does the 2023 TM Racing EN 530 Fi 4T have?

The 2023 TM Racing EN 530 Fi 4T has a Gearbox of 5-speed.

How much does the 2023 TM Racing EN 530 Fi 4T weigh?

The 2023 TM Racing EN 530 Fi 4T has a Dry weight of 115.0 kg (253.5 pounds).

What is the seat height of the 2023 TM Racing EN 530 Fi 4T?

The 2023 TM Racing EN 530 Fi 4T has a Seat height of 1,000 mm (39.4 inches) If adjustable, lowest setting..

TM Racing EN 530 Fi 4T - 2023 Specifications and Reviews

Name: 2023 TM Racing EN 530 Fi 4T
Brand: TM racing

The 2023 TM Racing EN 530 Fi 4T is a competitive enduro motorcycle designed for serious off-road enthusiasts seeking reliable performance in challenging terrain. Powered by a liquid-cooled 528cc four-stroke single-cylinder engine with fuel injection and DOHC technology, it delivers strong midrange power and precise throttle response. Best known for its rugged Italian engineering and capable handling, this machine excels in technical trail riding and enduro racing.

⇄ Compare against another bike 📅 All Years

2024

2023

❮❯

Add/Upload pictures for this motorcycle

General information
Category	Enduro / offroad
Year	2023
Model	TM Racing EN 530 Fi 4T

Engine and Transmission Specifications
Driveline	Regina ZSA chain
Clutch	Multiple-disk in oil-bath with hydraulic control
Transmission type	Chain (final drive)
Gearbox	5-speed
Cooling system	Liquid
Ignition	eMoticom
Fuel control	Double Overhead Cams/Twin Cam (DOHC)
Fuel system	Injection
Valves per Cylinder	4
Bore x Stroke	98.0 x 70.0 mm (3.9 x 2.8 inches)
Engine type	Single cylinder, four-stroke
Capacity:	528.0 ccm (32.22 cubic inches)
Brakes, suspension, Frame and wheels
Wheels	Wire spoked. Blue rims.
Rear brakes	Single disc. Nissin
Diameter	270 mm (10.6 inches)
Front brakes	Single disc. Brembo
Rear tire	140/80-19
Front tire	90/90-21
Rear wheel travel	300 mm (11.8 inches)
Rear Suspension	TM Racing
Front wheel travel	310 mm (12.2 inches)
Front Suspension	Kayaba 48 mm
Rake (fork angle)	27.0°
Frame type	Self-tempering aluminium deltabox type single beam with extruded, forged and microcast parts

Physical measures and capacities
Fuel capacity	7.50 litres (1.98 US gallons)
Ground clearance	360 mm (14.2 inches)
Seat height	1,000 mm (39.4 inches) If adjustable, lowest setting.
Dry weight	115.0 kg (253.5 pounds)
Other specs
Maintenance	Find parts, fluids, filters, maintenance tools and service items on eBay
Comments	Italian brand.
Starter	Electric
Color options	Blue/white

Performance Profile & Rider Fit

Best For

Track30%

City20%

Cornering80%

Daily Riding20%

Touring20%

Passenger5%

Rider Profile

Best For	This is a serious enduro machine best suited to experienced off-road riders comfortable with a tall seat, minimal weight, and a punchy big-bore four-stroke engine.
Purpose	Built for competitive enduro and technical trail riding, not for commuting or road touring.
Rider Fit	The 1000mm seat height and 115kg dry weight demand good rider fitness, leg length, and off-road technique to manage the bike at low speed and over obstacles.
Character	Light, race-bred, and aggressive, this TM rewards precise input with sharp handling and strong torque delivery from its 528cc DOHC single.
Not Ideal For	Not a good fit for beginners, tall-highway commuters, or anyone wanting a plush, low-maintenance daily ride.

Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.

Rider Fit Visualizer

2023 TM racing TM Racing EN 530 Fi 4T Rider Ergonomics Assessment

Your height

Inseam (optional)

Units

Calculated in your browser only - your height/inseam are never sent to our servers.

Feet:

At 1000mm, a rider of 175cm with a 79cm (estimated) inseam will reach the ground with cannot reach comfortably on the 2023 TM racing TM Racing EN 530 Fi 4T, with a moderate knee angle of around 90 degrees and an upright riding position.

Data quality: estimated (wheelbase estimated from this category's typical bike, not this model's own spec). Assumes about 30mm of suspension sag once seated (a typical street-bike rule of thumb - stiffer or softer suspension will vary). This is an approximation from category-typical geometry and generic body proportions, not a measurement of this specific bike or you - sit on it before you buy.

Find bikes that fit your height →

Shop This Bike

Find Parts for the TM Racing EN 530 Fi 4T 2023 Find One For Sale

Rider Reviews

Total comments: 1

MotorcycleDB Review

The 2023 TM Racing EN 530 Fi 4T is an impressive off-road motorcycle that offers top-notch performance and handling. With its powerful 530cc fuel-injected 4-stroke engine, this bike delivers exceptional power and torque for tackling any terrain. The high-quality suspension system and robust frame make it a reliable choice for off-road enthusiasts who demand the best in performance and durability. Whether you're hitting the trails or taking on challenging tracks, the TM Racing EN 530 Fi 4T provides an exhilarating ride that will leave you craving more. In addition to its impressive performance, the 2023 TM Racing EN 530 Fi 4T also boasts a sleek and modern design. The eye-catching aesthetics and attention to detail make this bike stand out from the crowd. With its advanced technology and innovative features, it's clear that TM Racing has created a motorcycle that is designed to impress. Whether you're a seasoned off-road rider or a beginner looking for a high-performance machine, the TM Racing EN 530 Fi 4T is a great choice that will not disappoint.
