What category is the 2025 Morbidelli T1002VX?

The 2025 Morbidelli T1002VX has a Category of Enduro / offroad.

What is the engine size of the 2025 Morbidelli T1002VX?

The 2025 Morbidelli T1002VX has a Capacity: of 997.0 ccm (60.85 cubic inches).

What type of engine does the 2025 Morbidelli T1002VX have?

The 2025 Morbidelli T1002VX has a Engine type of V2, four-stroke.

Is the 2025 Morbidelli T1002VX air cooled or liquid cooled?

The 2025 Morbidelli T1002VX has a Cooling system of Liquid.

What is the engine power of the 2025 Morbidelli T1002VX?

The 2025 Morbidelli T1002VX has a Power of 88.5 HP (66.0 kW) @ 7500 RPM.

What is the torque of the 2025 Morbidelli T1002VX?

The 2025 Morbidelli T1002VX has a Torque of 89.0 Nm (9.1 kgf-m or 65.6 ft.lbs) @ 5250 RPM.

How many gears does the 2025 Morbidelli T1002VX have?

The 2025 Morbidelli T1002VX has a Gearbox of 6-speed.

How much does the 2025 Morbidelli T1002VX weigh?

The 2025 Morbidelli T1002VX has a Weight incl. oil, gas, etc of 265.0 kg (584.2 pounds).

What is the seat height of the 2025 Morbidelli T1002VX?

The 2025 Morbidelli T1002VX has a Seat height of 820 mm (32.3 inches) If adjustable, lowest setting..

Morbidelli T1002VX - 2025 Specifications and Reviews

Name: 2025 Morbidelli T1002VX
Brand: Morbidelli MBP

The 2025 Morbidelli T1002VX is the off-road-oriented sibling to the T1002V, sharing the same 997cc V-twin, chassis, and touring equipment but swapping to wire-spoke wheels for greater off-road durability. Otherwise mechanically identical, it targets riders wanting more confidence on loose or rough surfaces.

⇄ Compare against another bike 📅 All Years

2026

2025

❮❯

Add/Upload pictures for this motorcycle

General information
Category	Enduro / offroad
Year	2025
Model	Morbidelli T1002VX
Engine and Transmission Specifications
Transmission type	Chain (final drive)
Clutch	Hydraulic, slipper function
Gearbox	6-speed
Torque	89.0 Nm (9.1 kgf-m or 65.6 ft.lbs) @ 5250 RPM
Power	88.5 HP (66.0 kW) @ 7500 RPM
Fuel system	Injection
Cooling system	Liquid
Engine details	80° V-twin
Engine type	V2, four-stroke
Capacity:	997.0 ccm (60.85 cubic inches)

Physical measures and capacities
Fuel capacity	20.00 litres (5.28 US gallons)
Overall height	1475 mm (58.1 inches)
Overall width	931 mm (36.7 inches)
Overall length	2313 mm (91.1 inches)
Ground clearance	190 mm (7.5 inches)
Seat height	820 mm (32.3 inches) If adjustable, lowest setting.
Wet weight (incl. fluids)	265.0 kg (584.2 pounds)

Morbidelli T1002VX dimensions and frame
Rear brakes	Single disc. 260 mm. Bosch ABS Pro.
Front brakes	Double disc. 320 mm. J.Juan calipers. Bosch ABS Pro.
Rear tire	17 inch, wire-spoke wheel
Front tire	Pirelli Scorpion Rally STR 120/70-R19, wire-spoke wheel
Rear suspension	KYB Multilink monoshock, fully adjustable, 77.4mm travel
Front suspension	43mm inverted fork, 183.8mm travel
Other specs
Maintenance	Find parts, fluids, filters, maintenance tools and service items on eBay
Comments	Cruise control, heated seat and grips, 4 rider modes, traction control, TPMS, height-adjustable screen, aluminium bash plate, crash bars. Wire-spoke wheels for off-road durability vs the alloy-wheeled T1002V.

Performance Profile & Rider Fit

88.5 hp

Peak Power

Best For

Track15%

City35%

Cornering40%

Daily Riding55%

Touring80%

Passenger55%

Rider Profile

Best For	Suited to riders wanting the T1002V's touring equipment with more confidence on loose or rough surfaces thanks to wire-spoke wheels.
Purpose	A value-focused adventure tourer built for mixed on/off-road long-distance travel with more off-road durability than the alloy-wheeled T1002V.
Rider Fit	An 820mm seat height and 265kg weight require reasonable rider confidence, offset by comprehensive standard touring equipment.
Character	Mechanically identical to the T1002V but with wire-spoke wheels for greater off-road resilience.
Not Ideal For	Not for serious technical off-road riding or riders wanting a lightweight, sporty adventure bike.

Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.

Rider Fit Visualizer

2025 Morbidelli MBP Morbidelli T1002VX Rider Ergonomics Assessment

Your height

Inseam (optional)

Units

Calculated in your browser only - your height/inseam are never sent to our servers.

Feet:

At 820mm, a rider of 175cm with a 79cm (estimated) inseam will reach the ground with balls of both feet on the 2025 Morbidelli MBP Morbidelli T1002VX, with a cramped knee angle of around 70 degrees and a slightly forward riding position.

Data quality: estimated (wheelbase estimated from this category's typical bike, not this model's own spec). Assumes about 30mm of suspension sag once seated (a typical street-bike rule of thumb - stiffer or softer suspension will vary). This is an approximation from category-typical geometry and generic body proportions, not a measurement of this specific bike or you - sit on it before you buy.
