Kawasaki KLX 230 SE - 2024 Specifications and Reviews
The 2024 Kawasaki KLX300 SM is a lightweight supermoto designed for new and intermediate riders seeking versatile street and light off-road capability. Its 292cc single-cylinder engine delivers manageable power with responsive handling, making it ideal for urban commuting and weekend adventures. Known for reliability and affordability, it excels as an accessible entry point into dual-sport riding.
General information | |
| Price as new | Do you know this bike?Click here to rate it. We miss 2 votes to show the rating. |
| Type | Super motard |
| Year model | 2024 |
| Model name | Kawasaki KLX300 SM |
| | |
Engine and Transmission Specifications | |
| Transmission type | Chain (final drive) |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Lubrication system | Forced, semi-dry sump |
| Ignition | CDI |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Fuel system | Injection. DFI® with 34mm Keihin throttle body |
| Valves per cylinder | 4 |
| Bore x stroke | 78.0 x 61.2 mm (3.1 x 2.4 inches) |
| Compression | 11.1:1 |
| Type of engine | Single cylinder, four-stroke |
| Capacity: | 292.0 ccm (17.82 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Rear brakes | Single disc. Petal disc with single-piston caliper |
| Diameter | 300 mm (11.8 inches) |
| Front brakes | Single disc. Petal disc with a dual-piston caliper |
| Rear tire | 130/70-17 |
| Front tire | 110/70-17 |
| Rear wheel travel | 206 mm (8.1 inches) |
| Rear suspension | Uni-Trak® gas charged shock with piggyback reservoir with adjustable rebound damping and spring preload |
| Front wheel travel | 231 mm (9.1 inches) |
| Front suspension | 43mm inverted cartridge fork with adjustable compression damping |
| Trail | 71 mm (2.8 inches) |
| Rake (fork angle) | 25.0° |
| Frame type | Semi Double Cradle |
Physical measures and capacities | |
| Fuel capacity | 7.57 litres (2.00 US gallons) |
| Wheelbase | 1435 mm (56.5 inches) |
| Ground clearance | 236 mm (9.3 inches) |
| Overall width | 790 mm (31.1 inches) |
| Overall length | 2195 mm (86.4 inches) |
| Overall height | 1146 mm (45.1 inches) |
| Seat height | 861 mm (33.9 inches) If adjustable, lowest setting. |
| Dry weight | 138.0 kg (304.3 pounds) |
| | |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Factory warranty | 12 months |
| Instruments | All-digital multi-function instrumentation |
| Starter | Electric |
| Color options | Neon Green, Ebony |
Performance Profile & Rider Fit
Best For
Track55%
City75%
Cornering85%
Daily Riding55%
Touring30%
Passenger25%
Rider Profile
| Best For | Note: the provided specifications describe a Kawasaki KLX300 SM supermoto, not the KLX 230 SE named, so this profile is based on that mismatched data. |
| Purpose | This is a lightweight supermoto built for flickable, playful riding on tight twisty roads and urban streets rather than long-distance touring or serious off-road work. |
| Rider Fit | A tall seat height combined with a light overall weight makes it manageable for most riders once they get accustomed to the reach to the ground. |
| Character | Nimble and eager, it rewards an aggressive, active riding style with sharp steering response and confident cornering manners. |
| Not Ideal For | It is not the right choice for riders wanting high-speed highway comfort, long-range touring capability, or serious off-road adventure travel. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
