Husqvarna TE 150 - 2024 Specifications and Reviews

2024

General information
Price as new	Do you know this bike?Click here to rate it. We miss 2 votes to show the rating.
Type	Enduro / offroad
Year model	2024
Model name	Husqvarna TE 150

Engine and Transmission Specifications
Driveline	X-Ring 5/8 x 1/4´
Clutch	DS wet multi-disc clutch, Braktec hydraulics
Transmission type	Chain (final drive)
Gearbox	6-speed
Cooling system	Liquid
Lubrication system	Mixture oil lubrication
Ignition	Continental EMS
Fuel system	Injection. 39 mm
Bore x stroke	58.0 x 54.4 mm (2.3 x 2.1 inches)
Engine details	Reed intake.
Type of engine	Single cylinder, two-stroke
Capacity:	144.0 ccm (8.79 cubic inches)
Brakes, suspension, Frame and wheels
Rear brakes	Single disc
Diameter	260 mm (10.2 inches)
Front brakes	Single disc
Rear tire	120/80-19
Front tire	90/90-21
Rear wheel travel	300 mm (11.8 inches)
Rear suspension	WP XACT Monoshock with linkage
Front wheel travel	300 mm (11.8 inches)
Front suspension	WP XPLOR-USD, Ø 48 mm
Rake (fork angle)	26.5°
Frame type	Central double-cradle-type 25CrMo4 steel

Physical measures and capacities
Fuel capacity	9.00 litres (2.38 US gallons)
Wheelbase	1471 mm (57.9 inches)
Ground clearance	360 mm (14.2 inches)
Overall length	2235 mm (88.0 inches)
Overall height	1230 mm (48.4 inches)
Seat height	950 mm (37.4 inches) If adjustable, lowest setting.
Dry weight	99.6 kg (219.6 pounds)
Other specs
Update specs
Comments	Two engine maps.
Factory warranty	2 Years
Electrical	Lithium-ion battery
Instruments	Digital
Starter	Electric & kick
Color options	White/blue/yellow
