Husqvarna TC 50 Mini - 2024 Specifications and Reviews
Engine and Transmission Specifications | |
| Driveline | 1/2 x 3/16´ chain |
| Clutch | Centrifugal clutch (adjustable) |
| Transmission type | Chain (final drive) |
| Gearbox | Automatic |
| Cooling system | Liquid |
| Lubrication system | Mixture oil lubrication |
| Ignition | Seletra 2p D36 |
| Bore x stroke | 39.5 x 40.0 mm (1.6 x 1.6 inches) |
| Type of engine | Single cylinder, two-stroke |
| Capacity: | 49.0 ccm (2.99 cubic inches) |
| | |
| Price as new | Do you know this bike?Click here to rate it. We miss 2 votes to show the rating. |
| Type | Minibike, cross |
| Year model | 2024 |
| Model | Husqvarna TC 50 Mini |
Brakes, suspension, Frame and wheels | |
| Rear brakes | Single disc |
| Diameter | 160 mm (6.3 inches) |
| Front brakes | Single disc |
| Rear wheel travel | 147 mm (5.8 inches) |
| Rear suspension | XACT WP PDS mono shock |
| Front wheel travel | 100 mm (3.9 inches) |
| Front suspension | XACT 35 WP Upside-Down fork, Ø 35 mm |
| Rake (fork angle) | 22.6° |
| Frame type | Chrome-molybdenum steel central-tube |
Physical measures and capacities | |
| Oil capacity | 0.90 litres (0.95 US quarts) |
| Fuel capacity | 2.30 litres (0.61 US gallons) |
| Wheelbase | 1032 mm (40.6 inches) |
| Ground clearance | 168 mm (6.6 inches) |
| Seat height | 558 mm (22.0 inches) If adjustable, lowest setting. |
| Dry weight | 40.0 kg (88.2 pounds) |
| | |
Other specs | |
| Update specs | |
| Comments | Power reduction kit available. |
| Factory warranty | 2 Years |
| Starter | Kick |
| Color options | White/grey/yellow |
