What category is the 2016 Honda Wave 100R?

The 2016 Honda Wave 100R has a Category of Scooter.

What is the engine size of the 2016 Honda Wave 100R?

The 2016 Honda Wave 100R has a Capacity: of 97.10 ccm (5.93 cubic inches).

What type of engine does the 2016 Honda Wave 100R have?

The 2016 Honda Wave 100R has a Engine type of Single cylinder, four-stroke.

What is the engine power of the 2016 Honda Wave 100R?

The 2016 Honda Wave 100R has a Power of 7.30.

What is the torque of the 2016 Honda Wave 100R?

The 2016 Honda Wave 100R has a Torque of 7.34 Nm (0.7 kgf-m or 5.4 ft.lbs) @ 5500.

Is the 2016 Honda Wave 100R air cooled or liquid cooled?

The 2016 Honda Wave 100R has a Cooling system of Air.

How many gears does the 2016 Honda Wave 100R have?

The 2016 Honda Wave 100R has a Gearbox of Automatic.

How much does the 2016 Honda Wave 100R weigh?

The 2016 Honda Wave 100R has a Dry weight of 91.5 kg (201.7 pounds).

What is the seat height of the 2016 Honda Wave 100R?

The 2016 Honda Wave 100R has a Seat height of 751 mm (29.6 inches) If adjustable, lowest setting..

Honda Wave 100R - 2016 Specifications and Reviews

Name: 2016 Honda Wave 100R
Brand: Honda

⇄ Compare against another bike 📅 All Years

2016

Add/Upload pictures for this motorcycle

General information
Category	Scooter
Year	2016
Model	Honda Wave 100R

Engine and Transmission Specifications
Exhaust system	Muffler coated with a special anti corrosion paint on the inside
Transmission type,final drive	Belt
Gearbox	Automatic
Cooling system	Air
Ignition	AC-CDI (Capacitor Discharge Ignition)
Fuel control	OHC
Fuel system	Carburettor
Bore x stroke	50.0 x 49.5 mm (2.0 x 1.9 inches)
Torque	7.34 Nm (0.7 kgf-m or 5.4 ft.lbs) @ 5500
Power	7.30
Engine type	Single cylinder, four-stroke
Capacity:	97.10 ccm (5.93 cubic inches)
Brakes, suspension, Frame and wheels
Wheels	Spoke
Rear brakes	Expanding brake (drum brake)
Front brakes	Single disc. Hydraulic, ventilated
Rear tyre dimensions	2.25-17
Front tyre dimensions	2.25-17
Rear suspension	Twin shocks
Front suspension	Telescopic fork
Frame type	Steel
Physical measures and capacities
Oil capacity	0.90 litres (0.06 quarts)
Fuel capacity	3.70 litres (0.98 gallons)
Wheelbase	1,234 mm (48.6 inches)
Ground clearance	133 mm (5.2 inches)
Overall width	705 mm (27.8 inches)
Overall length	1,898 mm (74.7 inches)
Overall height	1,057 mm (41.6 inches)
Seat height	751 mm (29.6 inches) If adjustable, lowest setting.
Power/weight ratio	0.0798 HP/kg
Dry weight	91.5 kg (201.7 pounds)
Other specs
Maintenance	Find parts, fluids, filters, maintenance tools and service items on eBay
Comments	Cub sold in some Asian countries.
Color options	Blue, red, white, silver
Light	Dual headlight
Starter	Electric & kick

Performance Profile & Rider Fit

7.3 hp

Peak Power

Best For

Track2%

City92%

Cornering38%

Daily Riding90%

Touring8%

Passenger45%

Rider Profile

Best For	Ideal for complete beginners and everyday riders; forgiving, light and low-powered with an easy clutchless drivetrain that anyone can master quickly.
Purpose	A budget-friendly Asian-market cub built for short urban commutes, errands and school runs, prioritizing low running costs and fuel economy over speed.
Rider Fit	Very light at 91.5kg with a low 751mm seat and slim 705mm width; upright, compact ergonomics that suit shorter riders and easy footing in traffic.
Character	A humble, dependable little workhorse-cheap, economical and endlessly practical, with no pretensions to speed or excitement.
Not Ideal For	Not for highway travel, touring, spirited riding or taller riders wanting power; the 97cc engine and 3.7L tank limit it to short, low-speed trips.

Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.

Rider Fit Visualizer

2016 Honda Wave 100R Rider Ergonomics Assessment

Your height

Inseam (optional)

Units

Calculated in your browser only - your height/inseam are never sent to our servers.

Feet:

At 751mm, a rider of 175cm with a 79cm (estimated) inseam will reach the ground with both feet flat on the 2016 Honda Wave 100R, with a moderate knee angle of around 95 degrees and a slightly forward riding position.

Data quality: measured. Assumes about 30mm of suspension sag once seated (a typical street-bike rule of thumb - stiffer or softer suspension will vary). This is an approximation from category-typical geometry and generic body proportions, not a measurement of this specific bike or you - sit on it before you buy.
