Honda SH Mode 125 - 2024 Specifications and Reviews
The 2024 Honda SH Mode 125 is a practical urban scooter designed for commuters seeking reliable, fuel-efficient transportation. Powered by Honda's advanced eSP+ engine with Selectable Torque Control, it delivers smooth performance and easy handling in city environments. Best known for its dependable technology, comfortable ride, and low running costs, this scooter excels as an everyday commuter solution.
General information | |
| Category | Scooter |
| Year | 2023 |
| Model | Honda SH Mode 125 |
Engine and Transmission Specifications | |
| Greenhouse gases | 48.7 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel consumption | 2.10 litres/100 km (47.6 km/l or 112.01 mpg) |
| Driveline | CVT, V-Belt |
| Clutch | Automatic Centrifugal Clutch, Dry |
| Transmission type | Belt (final drive) |
| Gearbox | Automatic |
| Cooling system | Liquid |
| Ignition | Fully transistorised electronic |
| Fuel control | Single Overhead Cams (SOHC) |
| Fuel system | Injection. PGM-FI electronic fuel injection |
| Valves per Cylinder | 4 |
| Bore x Stroke | 53.5 x 55.5 mm (2.1 x 2.2 inches) |
| Compression | 11.5:1 |
| Torque | 12.1 Nm (1.2 kgf-m or 8.9 ft.lbs) @ 5000 RPM |
| Power | 11.3 HP (8.2 kW) @ 8500 RPM |
| Engine type | Single cylinder, four-stroke |
| Capacity: | 125.0 ccm (7.63 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Wheels | Cast aluminium |
| Rear brakes | Expanding brake (drum brake) |
| Diameter | 220 mm (8.7 inches) |
| Front brakes | Single disc. Hydraulic. |
| Rear tire | 100/90-14 |
| Front tire | 80/90-16 |
| Rear wheel travel | 75 mm (3.0 inches) |
| Rear Suspension | Unit swingarm |
| Front wheel travel | 89 mm (3.5 inches) |
| Front Suspension | Telescopic forks with hydraulic damping 31mm |
| Trail | 68 mm (2.7 inches) |
| Rake (fork angle) | 27.0° |
| Frame type | Under bone |
| | |
Physical measures and capacities | |
| Oil capacity | 0.90 litres (0.95 US quarts) |
| Fuel capacity | 5.60 litres (1.48 US gallons) |
| Wheelbase | 1305 mm (51.4 inches) |
| Ground clearance | 150 mm (5.9 inches) |
| Overall width | 670 mm (26.4 inches) |
| Overall length | 1950 mm (76.8 inches) |
| Overall height | 1100 mm (43.3 inches) |
| Seat height | 765 mm (30.1 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 118.0 kg (260.1 pounds) |
| | |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Comments | USB. |
| Light | Dual headlights |
| Electrical | 12V-5Ah battery. |
| Starter | Electric |
| Color options | Black Poseidon Metallic, Pearl Jasmin White, Candy Noble Red, Matte Techno Silver Metallic |
Performance Profile & Rider Fit
11.3 hp
Peak Power
Best For
Track3%
City95%
Cornering40%
Daily Riding88%
Touring15%
Passenger45%
Rider Profile
| Best For | Ideal for beginners and commuters; twist-and-go automatic with a low 765mm seat and light weight make it approachable for new or returning riders. |
| Purpose | Built for urban commuting and short errands-efficient, easy-parking city transport at over 100mpg with USB and underseat practicality. |
| Rider Fit | Light 118kg, low 765mm seat, upright feet-forward scooter ergonomics with step-through frame; 16in front/14in rear wheels aid stability. |
| Character | A frugal, friendly, no-fuss Honda city scooter-refined liquid-cooled 125 single, automatic CVT, and easygoing manners over practical fun. |
| Not Ideal For | Not for highway travel, long-distance touring, spirited sport riding, off-road use, or anyone wanting real speed and power. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
