Honda Montesa Cota 4RT 260R - 2024 Specifications and Reviews
The 2024 Honda Montesa Cota 4RT 260R is a lightweight trial motorcycle designed for riders seeking technical off-road competition and training. Known for its nimble handling and precision control, this 259cc single-cylinder machine excels in navigating obstacles and demanding terrain. Its liquid-cooled engine and five-speed gearbox deliver reliable power for both amateur and experienced trial riders.
General information | |
| Price as new | Do you know this bike?Click here to rate it. We miss 2 votes to show the rating. |
| Type | Trial |
| Year model | 2024 |
| Model | Honda Montesa Cota 4RT 260R |
| | |
Engine and Transmission Specifications | |
| Driveline | #520 chain; 10T/41T |
| Clutch | Mulitplate in oil bath |
| Transmission type | Chain (final drive) |
| Gearbox | 5-speed |
| Cooling system | Liquid |
| Ignition | Electronically controlled digital transistorized |
| Fuel control | Single Overhead Cams (SOHC) |
| Fuel system | Injection. PGM-FI |
| Valves per cylinder | 4 |
| Bore x stroke | 78.0 x 54.2 mm (3.1 x 2.1 inches) |
| Compression | 10.5:1 |
| Engine details | Honda engine |
| Type of engine | Single cylinder, four-stroke |
| Capacity: | 258.9 ccm (15.80 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Wheels | Wire spoked. Dunlop tyres. |
| Rear brakes | Single disc. 2-piston caliper and sintered metal pads |
| Diameter | 185 mm (7.3 inches) |
| Front brakes | Single disc. 4-piston caliper and sintered metal pads |
| Rear tire | 120/100-R18 |
| Front tire | 80/100-21 |
| Rear wheel travel | 170 mm (6.7 inches) |
| Rear suspension | 39mm Showa® telescopic fork w/ preload extensions adjustments |
| Front wheel travel | 157 mm (6.2 inches) |
| Front suspension | 39mm Showa® telescopic fork w/ preload extensions adjustments |
| Trail | 61 mm (2.4 inches) |
| Rake (fork angle) | 23.0° |
Physical measures and capacities | |
| Fuel capacity | 2.00 litres (0.53 US gallons) |
| Wheelbase | 1321 mm (52.0 inches) |
| Ground clearance | 335 mm (13.2 inches) |
| Overall width | 830 mm (32.7 inches) |
| Overall length | 2016 mm (79.4 inches) |
| Overall height | 1140 mm (44.9 inches) |
| Seat height | 650 mm (25.6 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 77.0 kg (169.8 pounds) |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Update specs | |
| Comments | Optional Race Kit. Model id: MRT2603E. |
| Starter | Kick |
| Color options | Black |
Performance Profile & Rider Fit
Best For
Track10%
City5%
Cornering60%
Daily Riding5%
Touring3%
Passenger0%
Rider Profile
| Best For | This is a specialist trials machine best suited to riders with prior off-road or trials experience, though dedicated beginners can learn on it under guidance. |
| Purpose | Built purely for competitive and recreational trials riding, tackling obstacles, rocks, logs, and steep technical terrain at very low speeds. |
| Rider Fit | Its extremely light weight and low seat height make it accessible to smaller or lighter riders, but trials riding demands strong core balance, leg strength, and stamina for standing control. |
| Character | An ultra-light, razor-responsive machine that rewards precision, balance, and finesse over outright speed or comfort. |
| Not Ideal For | This is not a bike for anyone wanting a comfortable commuter, a highway tourer, or a passenger-friendly ride. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
