Honda CB500F - 2024 Specifications and Reviews
The 2024 Honda CB500F is a lightweight naked bike powered by a 471cc parallel-twin engine producing 47 horsepower, making it ideal for novice riders and commuters seeking an accessible, manageable platform. Known for its forgiving ergonomics, fuel efficiency, and affordable entry into motorcycling, the CB500F balances everyday practicality with enough performance to grow with the rider's skills.
General information | |
| Price as new | Do you know this bike?Click here to rate it. We miss 2 votes to show the rating. |
| Category | Naked bike |
| Model year | 2024 |
| Model | Honda CB500F |
Engine and Transmission Specifications | |
| Emission details | Euro 5 |
| Greenhouse gases | 81.2 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel consumption | 3.50 litres/100 km (28.6 km/l or 67.21 mpg) |
| Driveline | O-ring-sealed chain; 15T/41T |
| Clutch | Wet multiplate, assist/slipper clutch |
| Transmission type | Chain (final drive) |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Ignition | Computer-controlled digital transistorized with electronic advance |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Fuel system | Injection. PGM-FI with 34mm throttle bodies |
| Valves per cylinder | 4 |
| Bore x stroke | 67.0 x 66.8 mm (2.6 x 2.6 inches) |
| Compression | 10.7:1 |
| Torque | 43.0 Nm (4.4 kgf-m or 31.7 ft.lbs) @ 6500 RPM |
| Power output | 46.9 HP (34.3 kW)) @ 8600 RPM |
| Engine type | Twin, four-stroke |
| Capacity: | 471.0 ccm (28.74 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Rear brakes | Single disc. ABS. |
| Diameter | 295 mm (11.6 inches) |
| Front brakes | Single disc. ABS. 4-piston calipers. |
| Rear tire | 160/60-17 |
| Front tire | 120/70-R17 |
| Rear wheel travel | 119 mm (4.7 inches) |
| Rear suspension | Pro-Link® single shock with nine-position spring-preload adjustability |
| Front wheel travel | 120 mm (4.7 inches) |
| Front suspension | Showa 41mm SFF-BP USD forks |
| Trail | 102 mm (4.0 inches) |
| Rake (fork angle) | 25.5° |
| Frame type | Diamond tube |
| | |
Physical measures and capacities | |
| Oil capacity | 2.70 litres (2.85 US quarts) |
| Fuel capacity | 16.70 litres (4.41 US gallons) |
| Wheelbase | 1410 mm (55.5 inches) |
| Ground clearance | 145 mm (5.7 inches) |
| Overall width | 800 mm (31.5 inches) |
| Overall length | 2080 mm (81.9 inches) |
| Overall height | 1060 mm (41.7 inches) |
| Seat height | 790 mm (31.1 inches) If adjustable, lowest setting. |
| Power/weight ratio | 0.2445 HP/kg |
| Weight incl. oil, gas, etc | 189.0 kg (416.7 pounds) |
| Dry weight | 192.0 kg (423.3 pounds) |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Comments | Security system. Noise Level L-urban: 74dB L-wot: 76.4dB. Model id: CB500FA. |
| Factory warranty | One year. Transferable. Unlimited-mileage. |
| Light | Full LED lighting |
| Instruments | LCD Meter with Speedometer, Bar Graph Tachometer, Dual Trip Meters, Fuel Level and Consumption Gauge, Clock, Water Temp, Gear position, Shift UP Indicator |
| Starter | Electric |
| Color options | Matte Grey Metallic |
Maintenance and service data | |
| Fork tube size | 41 mm (1.6 inches) |
| Tire pressure rear | 42 PSI (2.9 Bar or 290 kPa) |
| Tire pressure front | 36 PSI (2.5 Bar or 250 kPa) |
| Sprockets | 15/41 (front/rear) |
| Chain links | 112 |
| Chain size | 520 |
| Spark plugs | NGK CPR8EA-9 |
| Battery | YTZ10S |
| Coolant | 2.00 litres (0.53 US gallons) |
| Brake fluid | DOT 4 |
| Update specs | SAE 10W-30 |
Performance Profile & Rider Fit
46.9 hp
Peak Power
5.8s
0-60 mph
Best For
Track35%
City85%
Cornering70%
Daily Riding88%
Touring45%
Passenger50%
Rider Profile
| Best For | This bike suits new-to-intermediate riders thanks to its modest power, light weight, and manageable seat height. |
| Purpose | It's built primarily as an approachable, affordable everyday naked bike for commuting and learning the ropes rather than chasing top speed. |
| Rider Fit | The low seat height and slim, lightweight chassis make it easy for riders of most heights and builds to handle confidently. |
| Character | It has a friendly, forgiving character with smooth low-mid range torque delivery and nimble, predictable handling around town. |
| Not Ideal For | It's not the right choice for riders wanting high-speed thrills, serious off-road capability, or long-distance two-up touring comfort. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
