Harley-Davidson Freewheeler - 2024 Specifications and Reviews
The 2024 Harley-Davidson Freewheeler is a three-wheeled cruiser powered by the Milwaukee-Eight 114 engine delivering 90 horsepower. Designed for riders seeking stable, comfortable long-distance cruising with classic custom styling, it combines traditional Harley character with the added stability and cargo capacity of a trike configuration. Best known for its approachable performance and relaxed riding position, it appeals to cruiser enthusiasts wanting an alternative to two-wheel motorcycles.
General information | |
| Price as new | Do you know this bike?Click here to rate it. We miss 2 votes to show the rating. |
| Category | Custom / cruiser |
| Model year | 2024 |
| Motorcycle name | Harley-Davidson Freewheeler |
Engine and Transmission Specifications | |
| Exhaust system | Shorty slash down-style chrome finish mufflers |
| Greenhouse gases | 126.9 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel consumption | 5.47 litres/100 km (18.3 km/l or 43.00 mpg) |
| Driveline | Chain, 34/46 ratio primary drive |
| Clutch | Multi-plate with diaphragm spring in oil bath |
| Transmission type | Belt (final drive) |
| Gearbox | 6-speed |
| Cooling system | Oil & air |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Fuel system | Injection. Electronic Sequential Port Fuel Injection |
| Bore x stroke | 102.0 x 114.3 mm (4.0 x 4.5 inches) |
| Compression | 10.5:1 |
| Power output | 90.0 HP (65.7 kW)) @ 4750 RPM |
| Engine details | Milwaukee-Eight™ 114 |
| Engine type | V2, four-stroke |
| Capacity: | 1868.0 ccm (113.99 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Wheels | Cast Aluminum. Dunlop® Harley-Davidson Series tires. |
| Rear brakes | Expanding brake (drum brake). 2-piston caliper. ABS. |
| Front brakes | Double disc. 4 piston caliper. ABS. |
| Rear tire | 215/45-R18 |
| Front tire | 130/60-B19 |
| Rear suspension | Hand-adjustable emulsion rear suspension |
| Front suspension | Telescopic fork, 49mm dual bending valve |
| Trail | 101 mm (4.0 inches) |
| Rake (fork angle) | 26.0° |
Physical measures and capacities | |
| Oil capacity | 4.70 litres (4.97 US quarts) |
| Fuel capacity | 22.71 litres (6.00 US gallons) |
| Wheelbase | 1670 mm (65.7 inches) |
| Ground clearance | 125 mm (4.9 inches) |
| Overall length | 2615 mm (103.0 inches) |
| Seat height | 665 mm (26.2 inches) If adjustable, lowest setting. |
| Power/weight ratio | 0.1847 HP/kg |
| Weight incl. oil, gas, etc | 503.5 kg (1,110.0 pounds) |
| Dry weight | 487.2 kg (1,074.0 pounds) |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Comments | Trike. Traction control. Cruise control. Foot actuated dual parking brake. |
| Carrying capacity | Trunk, 2 cu ft |
| Light | Dual halogen headlight 55-watt 625 lumen low beam, 65-watt 1,570 lumen high beam, Incandescent tail/stop, front signal lights and rear turn signals |
| Instruments | Speedometer, fuel gauges; display features odometer, trip A, trip B, range to empty, and gear indicator |
| Starter | Electric |
| Color options | Vivid Black, White Sand Pearl, Bright Billiard Blue/Billiard Grey |
Performance Profile & Rider Fit
90 hp
Peak Power
6.2s
0-60 mph
Best For
Track5%
City35%
Cornering15%
Daily Riding55%
Touring75%
Passenger80%
Rider Profile
| Best For | Best suited to experienced riders, since this is a three-wheeled trike that handles more like a car than a conventional motorcycle and requires its own learning curve. |
| Purpose | Built for relaxed, stable cruising and boulevard presence rather than outright speed or sporty handling. |
| Rider Fit | The low 665mm seat height and no-balance-required trike layout make it very approachable for shorter or less physically confident riders, though its substantial weight demands care at low speeds and in tight maneuvers. |
| Character | A laid-back, torque-rich cruiser personality with big V-twin thump, chrome styling, and the confidence of never having to put a foot down at a stoplight. |
| Not Ideal For | Not for riders seeking agile cornering, off-road capability, or a lightweight, quick-handling machine. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
