Harley-Davidson Fat Boy 114 - 2024 Specifications and Reviews
No pictures availableGeneral information | |
| Price as new | 4.0 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
| Type | Custom / cruiser |
| Year model | 2024 |
| Motorcycle name | Harley-Davidson Fat Boy 114 |
| | |
Engine and Transmission Specifications | |
| Exhaust system | 2-into-2 staggered, catalyst in muffler |
| Greenhouse gases | 116.0 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel consumption | 5.00 litres/100 km (20.0 km/l or 47.04 mpg) |
| Driveline | 34/46 ratio primary |
| Clutch | Multi-plate with diaphragm spring in oil bath |
| Transmission type | Belt (final drive) |
| Gearbox | 6-speed |
| Cooling system | Air |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Fuel system | Injection. Electronic Sequential Port Fuel Injection |
| Bore x stroke | 102.0 x 114.0 mm (4.0 x 4.5 inches) |
| Compression | 10.5:1 |
| Torque | 161.4 Nm (16.5 kgf-m or 119.0 ft.lbs) @ 3000 RPM |
| Effect | 94.0 HP (68.6 kW)) @ 5020 RPM |
| Engine details | Milwaukee-Eight® 114 |
| Type of engine | V2, four-stroke |
| Capacity: | 1868.0 ccm (113.99 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Wheels | Machined, Lakester cast aluminum wheels. Michelin® Scorcher® ´11´ tires. |
| Rear brakes | Single disc. Optional ABS. 2-piston. |
| Front brakes | Double disc. Optional ABS. 4-piston. |
| Rear tire | 240/40-R18 |
| Front tire | 160/60-R18 |
| Rear suspension | Hidden, free piston, coil-over monoshock; 43mm stroke; toolless hydraulic preload adjustment |
| Front suspension | Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring; ´beer can´ covers |
| Trail | 104 mm (4.1 inches) |
| Rake (fork angle) | 30.0° |
Physical measures and capacities | |
| Oil capacity | 4.70 litres (4.97 US quarts) |
| Fuel capacity | 18.93 litres (5.00 US gallons) |
| Wheelbase | 1666 mm (65.6 inches) |
| Ground clearance | 114 mm (4.5 inches) |
| Overall length | 2370 mm (93.3 inches) |
| Seat height | 658 mm (25.9 inches) If adjustable, lowest setting. |
| Power/weight ratio | 0.3088 HP/kg |
| Weight incl. oil, gas, etc | 317.1 kg (699.0 pounds) |
| Dry weight | 304.4 kg (671.0 pounds) |
Other specs | |
| Comments | Security system. Cruise control. |
| Light | All LED |
| Instruments | 5-inch analog speedometer with digital gear, odometer, fuel level, clock, trip, range and tachometer indication |
| Starter | Electric |
| Color options | Vivid Black, Bright Billiard Blue, Gray Haze/Silver Fortune, Heirloom Red Fade |
