Harley-Davidson CVO Road Glide Limited - 2024 Specifications and Reviews
The 2024 Harley-Davidson CVO Road Glide Limited is a premium cruiser-touring motorcycle designed for long-distance riders seeking comfort and advanced technology. Powered by the Twin-Cooled Milwaukee-Eight 117 engine producing 102 horsepower and 169.5 Nm of torque, it excels at highway cruising with its expansive fairing, refined handling, and luxury appointments that define the CVO lineup's exclusive character.
2024
General information | |
| Price as new | Do you know this bike?Click here to rate it. We miss 2 votes to show the rating. |
| Category | Touring |
| Year | 2024 |
| Model | Harley-Davidson CVO Road Glide Limited |
Engine and Transmission Specifications | |
| Exhaust system | Dual, with crossover |
| Greenhouse gases | 133.2 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel consumption | 5.74 litres/100 km (17.4 km/l or 40.98 mpg) |
| Driveline | Chain, 34/46 ratio primary drive |
| Clutch | Multi-plate with diaphragm spring in oil bath |
| Transmission type | Belt (final drive) |
| Gearbox | 6-speed |
| Cooling system | Oil & air |
| Lubrication system | Dry sump |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Fuel system | Injection. Electronic Sequential Port Fuel Injection |
| Bore x stroke | 4.1 x 114.3 mm (0.2 x 4.5 inches) |
| Compression | 10.2:1 |
| Torque | 169.5 Nm (17.3 kgf-m or 125.0 ft.lbs) @ 3500 RPM |
| Power | 102.0 HP (74.5 kW)) @ 4750 RPM |
| Engine details | Twin-Cooled™ Milwaukee-Eight® 117 |
| Engine type | V2, four-stroke |
| Capacity: | 1917.4 ccm (117.00 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Wheels | Gloss Black and Contrast Chrome Tomahawk. Dunlop® Harley-Davidson Series, bias blackwall tires. |
| Rear brakes | Single disc. ABS. 4-piston |
| Front brakes | Double disc. ABS. 4-piston |
| Rear tire | 180/55-B18 |
| Front tire | 130/60-B19 |
| Rear suspension | Twin shocks, Premium standard height hand-adjustable rear suspension |
| Front suspension | Telescopic fork, 49 mm dual bending valve |
| Trail | 170 mm (6.7 inches) |
| Rake (fork angle) | 26.0° |
| | |
Physical measures and capacities | |
| Oil capacity | 4.70 litres (4.97 US quarts) |
| Fuel capacity | 22.71 litres (6.00 US gallons) |
| Wheelbase | 1625 mm (64.0 inches) |
| Ground clearance | 130 mm (5.1 inches) |
| Overall length | 2570 mm (101.2 inches) |
| Seat height | 716 mm (28.2 inches) If adjustable, lowest setting. |
| Power/weight ratio | 0.2426 HP/kg |
| Weight incl. oil, gas, etc | 436.8 kg (963.0 pounds) |
| Dry weight | 420.5 kg (927.0 pounds) |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Update specs | |
| Comments | Small windshield. Heated seats and grips. Cruise control. Alarm. Infotainment. Bluetooth. USB. Cornering Electronically Linked Brakes, Cornering-ABS, Cornering-Traction Control with modes, Drag Torque Slip Control, Hill Hold Control (HHC), Tire Pressure Monitoring (TPMS). |
| Carrying capacity | Saddle bags. Top box. 4.7 cu ft luggage volume. |
| Light | LED headlight |
| Instruments | 6.5 inch color TFT. Gauges styled to complement each vehicle. Display features odometer, trip A, trip B, range to empty and gear indicator; and larger tell-tale indicators. |
| Starter | Electric |
| Color options | Heirloom Fade (Black/red) |
Performance Profile & Rider Fit
102 hp
Peak Power
4.3s
0-60 mph
Best For
Track10%
City35%
Cornering40%
Daily Riding55%
Touring97%
Passenger90%
Rider Profile
| Best For | Best suited to experienced riders who are comfortable managing a very heavy, long-wheelbase machine at low speeds and in traffic. |
| Purpose | Built for effortless, high-comfort long-distance touring with premium creature comforts rather than outright speed or sportiness. |
| Rider Fit | Riders benefit from decent height and upper body strength to handle the bike's substantial weight during parking, U-turns, and slow maneuvers. |
| Character | Suits a laid-back, image-conscious cruiser rider who values torque-rich low-end power, plush amenities, and a commanding highway presence over cornering agility. |
| Not Ideal For | Not a good fit for riders seeking sharp handling, off-road capability, or a lightweight, nimble city commuter. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
