What category is the 2020 Haojue KA135?

The 2020 Haojue KA135 has a Category of Underbone.

What is the engine size of the 2020 Haojue KA135?

The 2020 Haojue KA135 has a Capacity: of 135.0 ccm (8.24 cubic inches).

What type of engine does the 2020 Haojue KA135 have?

The 2020 Haojue KA135 has a Engine type of Single cylinder, four-stroke.

Is the 2020 Haojue KA135 air cooled or liquid cooled?

The 2020 Haojue KA135 has a Cooling system of Air.

What is the engine power of the 2020 Haojue KA135?

The 2020 Haojue KA135 has a Power of 10.9 HP (8.0 kW).

What is the torque of the 2020 Haojue KA135?

The 2020 Haojue KA135 has a Torque of 10.5 Nm.

How many gears does the 2020 Haojue KA135 have?

The 2020 Haojue KA135 has a Gearbox of 5-speed.

What is the seat height of the 2020 Haojue KA135?

The 2020 Haojue KA135 has a Seat height of 760 mm (29.9 inches) If adjustable, lowest setting..

How much does the 2020 Haojue KA135 weigh?

The 2020 Haojue KA135 has a Weight incl. oil, gas, etc of 128.0 kg (282.2 pounds).

Haojue KA135 - 2020 Specifications and Reviews

Name: 2020 Haojue KA135
Brand: Haojue

⇄ Compare against another bike 📅 All Years

2020

❮❯

Add/Upload pictures for this motorcycle

General information
Category	Underbone
Year	2020
Model	Haojue KA135
Engine and Transmission Specifications
Gearbox	5-speed
Torque	10.5 Nm
Power	10.9 HP (8.0 kW)
Cooling system	Air
Engine type	Single cylinder, four-stroke
Capacity:	135.0 ccm (8.24 cubic inches)
Brakes, suspension, Frame and wheels
Rear brakes	Expanding brake (drum brake)
Front brakes	Single disc
Rear tire	90/90-18
Front tire	2.75-18
Rear Suspension	Twin shocks
Front Suspension	Telescopic fork

Physical measures and capacities
Weight incl. oil, gas, etc	128.0 kg (282.2 pounds)
Fuel capacity	12.00 litres (3.17 US gallons)
Wheelbase	1285 mm (50.6 inches)
Ground clearance	170 mm (6.7 inches)
Seat height	760 mm (29.9 inches) If adjustable, lowest setting.
Other specs
Maintenance	Find parts, fluids, filters, maintenance tools and service items on eBay
Comments	Popular in Bangladesh market.
Starter	Electric & kick

Performance Profile & Rider Fit

10.9 hp

Peak Power

Best For

Track5%

City85%

Cornering55%

Daily Riding80%

Touring25%

Passenger30%

Rider Profile

Best For	This is an easy, forgiving machine well suited to beginners and commuters with little or no prior riding experience.
Purpose	It is built primarily for low-cost daily commuting and short urban trips rather than performance or adventure riding.
Rider Fit	Its light weight and low seat height make it very manageable for smaller or less physically strong riders.
Character	The KA135 is a practical, no-frills underbone with a friendly, unintimidating personality suited to everyday transport.
Not Ideal For	This is not the bike for riders seeking highway speed, long-distance touring comfort, or off-road capability.

Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.

Rider Fit Visualizer

2020 Haojue KA135 Rider Ergonomics Assessment

Your height

Inseam (optional)

Units

Calculated in your browser only - your height/inseam are never sent to our servers.

Feet:

At 760mm, a rider of 175cm with a 79cm (estimated) inseam will reach the ground with both feet flat on the 2020 Haojue KA135, with a moderate knee angle of around 110 degrees and a slightly forward riding position.

Data quality: measured. Assumes about 30mm of suspension sag once seated (a typical street-bike rule of thumb - stiffer or softer suspension will vary). This is an approximation from category-typical geometry and generic body proportions, not a measurement of this specific bike or you - sit on it before you buy.

Find bikes that fit your height →
