GAS GAS SM 515 Supermotard - 2009 Specifications and Reviews
2009
General information | |
| Category | Super motard |
| Year | 2009 |
| Model | GAS GAS SM 515 Supermotard |
| | |
Engine and Transmission Specifications | |
| Clutch | Multidisc in oil bath, hydraulically operated. |
| Transmission type,final drive | Chain |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Lubrication system | By fuel mixture. |
| Ignition | Integrated in the injection system. |
| Fuel system | Injection. EFI |
| Valves per cylinder | 4 |
| Bore x stroke | 97.0 x 60.8 mm (3.8 x 2.4 inches) |
| Engine type | Single cylinder, four-stroke |
| Capacity: | 492.00 ccm (30.02 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Rear brakes diameter | 220 mm (8.7 inches) |
| Rear brakes | Single disc |
| Front brakes diameter | 300 mm (11.8 inches) |
| Front brakes | Single disc. 2 pistons caliper |
| Rear tyre dimensions | 150/60-17 |
| Front tyre dimensions | 120/60-17 |
| Rear suspension travel | 320 mm (12.6 inches) |
| Rear suspension | One-piece aluminium swing arm. Sachs shock absorber. |
| Front suspension travel | 290 mm (11.4 inches) |
| Front suspension | 45 mm upside-down fork |
| Frame type | Deltabox* built with ´D´ profile CrMo tubing |
| | |
Physical measures and capacities | |
| Fuel capacity | 7.50 litres (1.98 gallons) |
| Wheelbase | 1,465 mm (57.7 inches) |
| Ground clearance | 255 mm (10.0 inches) |
| Seat height | 900 mm (35.4 inches) If adjustable, lowest setting. |
| Dry weight | 119.0 kg (262.4 pounds) |
Other specs | |
| Color options | Black/yellow |
| Starter | Electric & kick |
