What category is the 2014 Atlas Honda Deluxe 125?

The 2014 Atlas Honda Deluxe 125 has a Category of Allround.

What is the engine size of the 2014 Atlas Honda Deluxe 125?

The 2014 Atlas Honda Deluxe 125 has a Capacity: of 124.10 ccm (7.57 cubic inches).

What type of engine does the 2014 Atlas Honda Deluxe 125 have?

The 2014 Atlas Honda Deluxe 125 has a Engine type of Single cylinder, four-stroke.

Is the 2014 Atlas Honda Deluxe 125 air cooled or liquid cooled?

The 2014 Atlas Honda Deluxe 125 has a Cooling system of Air.

How many gears does the 2014 Atlas Honda Deluxe 125 have?

The 2014 Atlas Honda Deluxe 125 has a Gearbox of 4-speed.

How much does the 2014 Atlas Honda Deluxe 125 weigh?

The 2014 Atlas Honda Deluxe 125 has a Dry weight of 112.0 kg (246.9 pounds).

What is the seat height of the 2014 Atlas Honda Deluxe 125?

The 2014 Atlas Honda Deluxe 125 has a Seat height of 743 mm (29.3 inches) If adjustable, lowest setting..

Atlas Honda Deluxe 125 - 2014 Specifications and Reviews

Name: 2014 Atlas Honda Deluxe 125
Brand: Atlas Honda

The 2014 Atlas Honda Deluxe 125 is a practical all-rounder designed for entry-level and commuter riders. Powered by a reliable 124cc single-cylinder four-stroke engine with a 4-speed manual transmission, it delivers dependable everyday performance. Known for its affordability and low maintenance requirements, this lightweight motorcycle excels in urban commuting and short-distance travel.

⇄ Compare against another bike 📅 All Years

2015

2014

❮❯

Add/Upload pictures for this motorcycle

General information
Category	Allround
Year	2014
Model	Atlas Honda Deluxe 125
Engine and Transmission Specifications
Driveline	Roller chain final drive
Transmission type,final drive	Chain
Gearbox	4-speed
Cooling system	Air
Ignition	CDI
Fuel control	Overhead Cams (OHC)
Fuel system	Carburettor
Bore x Stroke	56.5 x 49.5 mm (2.2 x 1.9 inches)
Engine type	Single cylinder, four-stroke
Capacity:	124.10 ccm (7.57 cubic inches)

Brakes, suspension, Frame and wheels
Rear brakes	Expanding brake (drum brake). Non-asbestos
Front brakes diameter	130 mm (5.1 inches)
Front brakes	Expanding brake (drum brake). Non-asbestos
Rear tyre	90/90-18
Front tyre	2.75-18
Rear Suspension	Swing Arm 68 mm Travel
Front Suspension	Telescopic Forke 103 mm Travel
Frame type	Diamond Type Steel
Physical measures and capacities
Fuel capacity	12.00 litres (3.17 gallons)
Wheelbase	1,278 mm (50.3 inches)
Ground clearance	137 mm (5.4 inches)
Overall width	731 mm (28.8 inches)
Overall length	1,911 mm (75.2 inches)
Overall height	1,017 mm (40.0 inches)
Seat height	743 mm (29.3 inches) If adjustable, lowest setting.
Dry weight	112.0 kg (246.9 pounds)
Other specs
Maintenance	Find parts, fluids, filters, maintenance tools and service items on eBay
Comments	Sold in Pakistan.
Electrical	12 Volt battery
Instruments	Analogue
Starter	Kick
Color options	Red, black

Performance Profile & Rider Fit

Best For

Track5%

City80%

Cornering35%

Daily Riding75%

Touring20%

Passenger25%

Rider Profile

Best For	This is an entry-level commuter bike well suited to brand-new riders or anyone wanting simple, low-stakes transportation.
Purpose	It's built for basic daily commuting and short local trips rather than performance riding or long-distance touring.
Rider Fit	Its light weight, low seat height and kick-start simplicity make it very manageable for riders of smaller stature or limited strength.
Character	It has an honest, no-frills mechanical character with a small air-cooled single, carburettor, drum brakes and a kick starter, prioritizing durability and low running costs over excitement.
Not Ideal For	It is not a good fit for riders seeking highway speed, off-road capability, or comfortable two-up long-distance touring.

Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.

Rider Fit Visualizer

2014 Atlas Honda Deluxe 125 Rider Ergonomics Assessment

Your height

Inseam (optional)

Units

Calculated in your browser only - your height/inseam are never sent to our servers.

Feet:

At 743mm, a rider of 175cm with a 79cm (estimated) inseam will reach the ground with both feet flat on the 2014 Atlas Honda Deluxe 125, with a moderate knee angle of around 105 degrees and a forward-leaning riding position.

Data quality: measured. Assumes about 30mm of suspension sag once seated (a typical street-bike rule of thumb - stiffer or softer suspension will vary). This is an approximation from category-typical geometry and generic body proportions, not a measurement of this specific bike or you - sit on it before you buy.

Find bikes that fit your height →

Shop This Bike

Find Parts for the Atlas Honda Deluxe 125 2014 Find One For Sale

Rider Reviews

Total comments: 1

MotorcycleDB Review

The 2014 Atlas Honda Deluxe 125 is a reliable and stylish motorcycle that offers a smooth and powerful ride. With its 125cc engine, this bike provides excellent performance and fuel efficiency. The comfortable seating position and well-balanced handling make it a great choice for both daily commuting and longer rides. The Deluxe 125 also comes with a durable build quality, ensuring that it can withstand the rigors of regular use. Overall, this motorcycle is a great option for riders looking for a combination of performance and style. If you're in the market for a reliable and efficient motorcycle, the 2014 Atlas Honda Deluxe 125 is definitely worth considering. With its powerful 125cc engine and comfortable riding experience, this bike is well-suited for both city commuting and highway cruising. Additionally, its durable construction ensures that it can handle the demands of regular use. Whether you're a new rider or a seasoned motorcyclist, the Deluxe 125 offers a great balance of performance and style.
